Name: Haldex AL430624 Ffabs Valve
SKU: al430624
Price: 338.49 USD
Availability: InStock

HALDEX part description

Voltage:	12
Valve Type:	4-Port ABS Valve
Reservoir Nipple Diameter:	.5 / 3/4 in.
Related Part:	A906960, AL919346, AQ40525, AQ964110
Port 4 Diameter:	0.375 in. (1 Supply Port with Filter)
Port 3 Diameter:	.375 in. (4 Spring Brake Ports)
Port 2 Diameter:	.375 in. (4 Delivery Ports)
Port 1 Diameter:	.375 in. (1 Control Port)
OEM Part Number:	N4306JD
Crack Pressure:	4.0 PSI
Freight Class:	70
VMRS Code:	013011068
UPC (GTIN):	767653129518
Harmonized Tariff Code:	8481200060

Haldex Full-Function ABS (FFABS) Valve

Crafted to the industry's highest standards for performance, reliability, and safety, the Haldex Full-Function ABS valve provides you with a dependable performance at all times. This component expedites service replacement with its pre-installed combination nipple that works for two ports of different sizes.

Features & Benefits

Patented and comes with integral spring brake control function
Guarantees easy serviceability with its pre-installed reservoir nipple with swivel and lock-nut feature
Fitted with filters in both the control and supply ports
With production part number engraved on the metal tag
Made standard with filters in the control and supply ports

Product Description

FFABS Valve

Application Summary

Replaces AL430611,Patented FFABS Valve with integral Spring Brake Control function.

Features & Benefits

Patented and comes with integral spring brake control function
Guarantees easy serviceability with its pre-installed reservoir nipple with swivel and lock-nut feature
Fitted with filters in both the control and supply ports
With production part number engraved on the metal tag
Made standard with filters in the control and supply ports

Haldex Full-Function ABS (FFABS) Valve

Product Attributes

Control Port Diameter	3/8 in.
Delivery Port Diameter	4 @ 3/8 in.
Freight Class	70
Opening Pressure	4.0 PSI
Reservoir Port Diameter	1 @ 1/2 in., 1 @ 3/4 in. (Nipple)
Spring Brake Port Diameter	4 @ 3/8 in.
Supply Port Diameter	3/8 in.
Valve Type	4-Port ABS Valve
Voltage	12V

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	8481200060
Harmonized Tariff Code (HTS)	8481200060
Remanufactured Part	N
Warranty Distance	100000
Warranty Distance UOM	MI
Warranty Special	36 MO, 200,000 MI=ABS - Antilock Braking Systems Including Haldex TRS (Valves, ECUs and Looms Only). 12 MO, 100,000 MI= All Other ABS - Antilock Braking Systems Components. See L20221W.pdf for warranty details
Warranty Time	12
Warranty Time UOM	MO
UPC	00767653129518
VMRS Code	013011068

Part Interchanges

HALDEX AL430624 Cross Reference

We have 18 alternatives for the AL430624 by HALDEX:

Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
