Grote 53052 - 4" Die-Cast Single-Face Lights - Double Contact
$1999
MSRP: $31.73
Save: $11.74
In stock
limited availability at this price!
. Learn more
GROTE part description
Technical specifications
| Material: | Acrylic Lens, Die-Cast Zinc Housing |
| Finish: | Chrome Plated |
| Color: | Red |
| Lens Color: | Red |
| Housing Color: | Black |
| Voltage: | 12V |
| Amperage: | .6A-2.1A |
| Mounting Type: | Pendant |
| Connection Type: | Blunt Cut |
| Size: | 4" |
| Regulations: | FMVSS 108 |
| Functions: | S, T, I |
| Bulb: | 1157, 32, 3 CP |
| Diameter: | 4" |
| # of Wires: | 2 |
Features & Benefits
- Double contact
- For use on vehicles under 80" wide
- Less than 75 sq cm of effective, projected luminous lens area
- Wire exit includes a grommet to protect the jacket from abrasion
| Color/Finish | Red/Black |
| Material | Die-cast/Acrylic |
| Voltage | 12V / .59A (P, T) / 2.1A (I) |
| Bulb Type | 1157, 32/3 CP |
| Lighting Technology | Incandescent |
Product Description
STT,4",RED,ZINC DCST,SNGL FACE,DBL CNTCT
Features & Benefits
- Double contact
- Double contact
- For use on vehicles under 80" wide
- For use on vehicles under 80" wide
- Less than 75 sq cm of effective, projected luminous lens area
- Less than 75 sq cm of effective, projected luminous lens area
- Wire exit includes a grommet to protect the jacket from abrasion
- Wire exit includes a grommet to protect the jacket from abrasion
Product Attributes
| Amperage | .6A-2.1A |
| Color | Red |
| Connection Type | Blunt Cut |
| Finish | Chrome Plated |
| Function | I,S,T |
| Housing Color | Black |
| Lens Color | Red |
| Material | Acrylic Lens, Die-Cast Zinc Housing |
| Mounting Type | Pendant |
| Number of Wires | 2 |
| Regulations | FMVSS 108 |
| Shape | Round |
| Voltage | 12V |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8512200000 |
| Refurbished Part | N |
| Remanufactured Part | N |
| UPC | 00089373002118 |
| VMRS Code | 034002013 |
Part Interchanges
GROTE 53052 Cross Reference
We have 7 alternatives for the 53052 by GROTE:
Established in 1901, Grote® is a world-class manufacturer and supplier of light components and smart visibility systems for heavy duty vehicles. From LED beacons to trailer connectors, Grote products provide effective solutions and added value to its customers in the agricultural, construction, freight, and mining industries. The company has been a major supplier to commercial vehicle manufacturers, utilizing the latest quality planning techniques and manufacturing systems as well as rigorous environmental testing to maintain their competitive edge. Grote also works closely with OEM distributors and fleet managers in developing new ways to maximize the efficiency of their products according to the demands of the market.
