Grote 47122-3 - SuperNova® 2 1/2" LED Clearance / Marker Light - Red, Multi Pack
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
GROTE part description
Technical specifications
| Material: | Polycarbonate Housing, Polycarbonate Lens |
| Color: | Red |
| Lens Color: | Red |
| Amperage: | .06A |
| Mounting Type: | Grommet, Bracket |
| Connection Type: | PL-10 |
| Size: | 2½" |
| Height: | .75" |
| Regulations: | FMVSS 108 |
| Functions: | P2 |
| Diameter: | 2.5" |
With encapsulant potting for total circuit board protection and hermetic lens-to-housing seal, Our SuperNova® 2 1/2" LED Clearance Marker Lights use the same UBS double-seal pigtails as incandescent versions for a quick Plug-and-Go® Retrofit. The tin-plated, solid-brass terminals are sealed to housing, to resist corrosion and eliminate failure causing leak paths.
Features & Benefits
- Hermetic lens-to-housing seal
- Encapsulant potting for total circuit-board protection
- Uses the same UBS double-seal pigtail as the incandescent version for a quick Plug-and-Go® retrofit
- Tin-plated, solid-brass terminals are sealed to housing, to resist corrosion and eliminate failure-causing leak paths
| Color/Finish | Red |
| Material | Polycarbonate |
| Voltage | 12V / .06A |
| Lighting Technology | LED |
Product Description
CLR/MKR LMP,2.5",RED,SUPERNOVALED,BULK
Features & Benefits
- Hermetic lens-to-housing seal
- Hermetic lens-to-housing seal
- Encapsulant potting for total circuit-board protection
- Encapsulant potting for total circuit-board protection
- Uses the same UBS double-seal pigtail as the incandescent version for a quick Plug-and-Go® retrofit
- Uses the same UBS double-seal pigtail as the incandescent version for a quick Plug-and-Go® retrofit
- Tin-plated, solid-brass terminals are sealed to housing, to resist corrosion and eliminate failure-causing leak paths
- Tin-plated, solid-brass terminals are sealed to housing, to resist corrosion and eliminate failure-causing leak paths
With encapsulant potting for total circuit board protection and hermetic lens-to-housing seal, Our SuperNova® 2 1/2" LED Clearance Marker Lights use the same UBS double-seal pigtails as incandescent versions for a quick Plug-and-Go® Retrofit. The tin-plated, solid-brass terminals are sealed to housing, to resist corrosion and eliminate failure causing leak paths.
Product Attributes
| Amperage | .06A |
| Color | Red |
| Function | P2 |
| LED | Y |
| Lens Color | Red |
| Material | Polycarbonate Lens, Polycarbonate Housing |
| Mounting Type | Grommet, Bracket |
| Regulations | FMVSS 108 |
| Shape | Round |
| Voltage | 12V |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8512200000 |
| Refurbished Part | N |
| Remanufactured Part | N |
| VMRS Code | 034004253 |
Part Interchanges
GROTE 47122-3 Cross Reference
We have 4 alternatives for the 47122-3 by GROTE:
Established in 1901, Grote® is a world-class manufacturer and supplier of light components and smart visibility systems for heavy duty vehicles. From LED beacons to trailer connectors, Grote products provide effective solutions and added value to its customers in the agricultural, construction, freight, and mining industries. The company has been a major supplier to commercial vehicle manufacturers, utilizing the latest quality planning techniques and manufacturing systems as well as rigorous environmental testing to maintain their competitive edge. Grote also works closely with OEM distributors and fleet managers in developing new ways to maximize the efficiency of their products according to the demands of the market.
