Name: Moog 450 U-Joint
SKU: 450
Price: 25.99 USD
Availability: InStock

FEDERAL MOGUL-MOOG part description

Engineered for optimal performance, MOOG® universal joints are machined to meet or exceed original equipment standards.

Over 70 years of aftermarket engineering and product expertise has made MOOG® an industry leader in driveline quality and customer satisfaction.

Greaseable - allows new grease to flush out contamination and moisture reducing corrosion and wear
Needle bearings and snap rings from an original equipment supplier
Nitrile rubber grease seals have compressed double lip design for protection from contaminants
Durable and strong with consistent heat treatment for good bearing hardness ratios
Bearing cups ground and slightly oversized to fit in a used drive shaft
Cross forging shape and flash provide easier installation and high strength

Part Specifications

U-JOINT SPECIFICATIONS

U-Joint Identification	4 Grooved Round Bearings
Bearing Type A	Round Grooved
Bearing Diameter A - Inch	1.181
Bearing Diameter A - mm	30
Length Measurement A	Outside of Groove to Outside of Groove
Length A - Inch	2.29
Length A - mm	58.15
Bearing Type B	Round Grooved
Bearing Diameter B - Inch	1.181
Bearing Diameter B - mm	30
Length Measurement B	Outside of Groove to Outside of Groove
Length B - Inch	2.29
Length B - mm	58.15
OE Series	Mitsubishi
Lubricateable	YES
Lube Fitting Location	Angled lube fitting in center of cross
Image	UJoint_4Grooved.tif

Product Description

Greaseable Premium Universal Joint

Application Summary

1990-1992 Daihatsu Rocky (Rear Driveshaft at Rear Axle, Rear Driveshaft at Transmission) (Qualifier: Premium); 1989 Dodge Raider (Rear Driveshaft at Rear Axle, Rear Driveshaft at Transmission) (Liter: 3.0 & Engine(cc): 2972 & Engine(ci): 181 & Cylinder: 6 & Block: V & Bore(in): 3.59 & Bore(mm): 91.1 & Stroke(in): 2.99 & Stroke(mm): 76.0 / Qualifier: Premium); 1990-1993 Dodge Ram 50 (Rear Driveshaft at Support Bearing, Rear Driveshaft at Transmission, Rear Driveshaft at Rear Axle) (Drive: 4WD / Qualifier: Premium); 1990-1994 Mitsubishi Mighty Max (Rear Driveshaft at Support Bearing, Rear Driveshaft at Transmission, Rear Driveshaft at Rear Axle) (Drive: 4WD / Qualifier: Premium); 1989-2000 Mitsubishi Montero (Rear Driveshaft at Rear Axle, Rear Driveshaft at Transmission) (Liter: 3.0, 3.5 & Engine(cc): 2972, 3497 & Engine(ci): 181, 215 & Cylinder: 6 & Block: V & Bore(in): 3.59, 3.66 & Bore(mm): 91.1, 93.0 & Stroke(in): 2.99, 3.37 & Stroke(mm): 76.0, 85.5 & Transmission Base Type: Transmission & Transmission Control Type: Automatic / Qualifier: Premium, From 12/2/1993); 1997-2004 Mitsubishi Montero Sport XLS Limited LS (At Transmission, At Rear Axle, At Center Bearing, Rear Driveshaft at Transmission, Rear Driveshaft at Rear Axle) (Liter: 3.0, 3.5 & Engine(cc): 2972, 3497 & Engine(ci): 181, 215 & Cylinder: 6 & Block: V & Bore(in): 3.59, 3.66 & Bore(mm): 91.1, 93.0 & Stroke(in): 2.99, 3.37 & Stroke(mm): 76.0, 85.5 & Drive: RWD, 4WD / Qualifier: Premium)

Features & Benefits

COMPREHENSIVE COVERAGE -- Available for foreign and domestic nameplates
GREASABLE DESIGN -- Greasable u-joints allow for new grease to flush out contaminants and moisture
KEEPS DIRT OUT -- Nitrile rubber grease seals use a compressed double lip design for effective protection against contaminants
RIGOROUS TESTING -- Comprehensive testing throughout design and development processes by MOOG engineers for quality you can count on
STRONG AND DURABLE -- Bearing cups are cold-forged, case-hardened and precision ground while steel cross is forged and carburized heat treated for strength and durability

Product Attributes

Length Axis 1	2.29 IN
Length Axis 1	58.15 MM
Length Axis 2	2.29 IN
Length Axis 2	58.15 MM
Bearing Cap Type	4 Grooved Round Bearings
Greasable	YES
Bearing Cap Axis 2 Diameter	1.181 IN
Bearing Cap Axis 2 Diameter	30 MM
Bearing Cap Axis 1 Diameter	1.181 IN
Bearing Cap Axis 1 Diameter	30 MM
Bearing Type A	Round Grooved
Bearing Type B	Round Grooved
Image	UJoint_4Grooved.tif
Length Measurement A	Outside of Groove to Outside of Groove
Length Measurement B	Inside of Groove to Inside of Groove plus thickness of 2 Lock Rings
LUBE FITTING LOCATION	Angled lube fitting in center of cross
OE Series	Mitsubishi
Part Description	Universal Joint
U-Joint Identification	4 Grooved Round Bearings

Additional Information

Country of Origin (Primary)	MX
Canadian Harmonizing Tariff Code	8708991510
Harmonized Tariff Code (Schedule B)	8708995800
Harmonized Tariff Code (HTS)	8708996810
UPC	00037551014538
VMRS Code	033003005

Part Interchanges

Fits Vehicles

Mitsubishi Montero Sport (1997-2004)
Mitsubishi Mighty Max (1990-1994)
Mitsubishi Montero (1989-2000)
Dodge Ram 50 (1990-1993)
Dodge Raider (1989)
Daihatsu Rocky (1990-1992)

For over 100 years, Moog® has been an industry leader in mid- to high-end aftermarket parts for steering, suspension, and driveline systems worldwide. Utilized by daily commuters to entire fleets, Moog parts have become synonymous with reliable performance that’s just as good or even better than their OE counterparts. Moog also incorporates innovative features in their products not found in competing products, such as patented forged steel bodies and metal “gusher” bearings that greatly reduce friction across moving components. The brand also leads the way in after-sales support, with comprehensive technical assistance and training materials available for customers around the world.
