Letrika MS530 - Starter 24V, 11T, CW, DD, Letrika/MAHLE AZG, 6.6kW, New
$60999
MSRP: $864.63
Save: $254.64
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
LETRIKA part description
Technical Data
| Product | Starter |
| Letrika P/N | IS9079 |
| Voltage | 24 V |
| Power | 6.6 kW |
| OEM P/N | 11.139.088 |
| MAHLE P/N | MS 530 |
| Description | AZK5440 |
| No. of pinion teeth | 11 |
| Module | 3 mm |
| Distance over two teeth | |
| Outside diameter of pinion | |
| Notes | Mass terminal 31 |
| Letrika P/N | OEM P/N | MAHLE P/N | |
|---|---|---|---|
| IS9079 | 11.139.088 AZK5440 24V 6,6kW | MS 530 | Available |
| IS9079 | 11.130.390 AZL3634 24V 6,5kW | Superseded unit, see available P/N IS9079 |
Related Parts
| Letrika P/N | MAHLE P/N | DESCRIPTION | POS |
|---|---|---|---|
| 16.909.019 | MSX 1200 | Switch | 5 |
| 16.909.020 | MSX 1272 | Pushing magnet | 6 |
| 16.909.047 | MSX 220 | Drive end bracket | 1 |
| 16.909.025 | MSX 239 | Connecting set | 4 |
| 16.909.002 | MSX 338 | Pinion | 2 |
| 16.909.007 | MSX 339 | Protecting cover | 10 |
| 16.909.014 | MSX 340 | Clutch cover | 14 |
| 16.909.139 | MSX 352 | Winding | 8 |
| 16.909.013 | MSX 450 | Clutch | 13 |
| 16.909.011 | MSX 529 | Fixing set | 11 |
| 16.909.010 | MSX 836 | Plunger | 9 |
| 16.909.008 | MSX 89 | Armature | 7 |
| 16.909.169 | MSX 948 | Set of brushes | 12 |
| 16.909.163 | MSX 96 | Rear-end bracket | 3 |
LETRIKA MS530 Cross Reference
We have 10 alternatives for the MS530 by LETRIKA:
