Letrika MS232 - Starter 24V, 9T, CW, PLGR, Letrika/MAHLE AZJ, 4kW, New
$34899
MSRP: $510.57
Save: $161.58
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
LETRIKA part description
Technical Data
| Product | Starter |
| Letrika P/N | IS0842 |
| Voltage | 24 V |
| Power | 4.0 kW |
| OEM P/N | 11.130.842 |
| MAHLE P/N | MS 232 |
| Description | AZF4515 |
| No. of pinion teeth | 9 |
| Module | 3 mm |
| Distance over two teeth | 14.36 mm |
| Outside diameter of pinion | 34.8 mm |
| Notes | With reduction gear |
| Letrika P/N | OEM P/N | MAHLE P/N | |
|---|---|---|---|
| IS0842 | 11.130.842 AZF4515 24V 4,0kW | MS 232 | Available |
| IS0842 | 11.130.673 AZJ3222 24V 4,0kW | MS 613 | Superseded unit, see available P/N IS0842 |
| IS0842 | 11.130.151 AZJ3522 24V 4,0kW | Superseded unit, see available P/N IS0842 |
Related Parts
| Letrika P/N | MAHLE P/N | DESCRIPTION | POS |
|---|---|---|---|
| 16.908.993 | MSX 1247 | Armature | 9 |
| 16.908.995 | MSX 1249 | Set of brushes | 14 |
| 16.908.994 | MSX 1262 | Brush holder | 13 |
| 16.915.142 | MSX 1413 | Switch | 4 |
| 16.908.335 | MSX 192 | Lever | 7 |
| 16.280.958 | MSX 197 | Stator | 12 |
| 16.908.340 | MSX 305 | Bearing | 10 |
| 16.904.832 | MSX 609 | Reduction gear | 8 |
| 16.285.394 | MSX 647 | Rear-end bracket | 15 |
| 16.285.395 | MSX 648 | Drive end bracket | 1 |
| 15.120.243 | MSX 684 | Bearing | 2 |
| 16.904.625 | MSX 724 | Pinion with clutch | 6 |
| 16.908.341 | MSX 787 | Fixing set | 11 |
LETRIKA MS232 Cross Reference
We have 34 alternatives for the MS232 by LETRIKA:
- AHLMAN N (MECALAC) 2300088A
- ATLAS COPCO 2913163700
- BOMAG 057 109 03
- BOSCH 0001231005
- BOSCH 0001263051
- BOSCH 0001263052
- BOSCH 0001364100
- BOSCH 0001364301
- BOSCH 0986011270
- BOSCH 0986012700
- BOSCH SR 925 X
- DELCO REMY DRS2700
- DEUTZ AG (KHD) 0116 3626
- DEUTZ AG (KHD) 0117 9586
- DEUTZ AG (KHD) 0118 0999
- FAUN 4159 015
- FUCHS541 165 6432
- HELLA 8EA 726 149-001
- HELLA CS 501
- LESTER 17045
- LESTER 18958
- LIEBHERR 620 06 62
- LIEBHERR 620 08 27
- LIEBHERR 702 60 25 A
- LUCAS LRS00960
- LUCAS LRS01936
- MAGNETI MARELLI 063522310050
- MAGNETI MARELLI 9432 522 15
- MAGNETI MARELLI MSR 705
- SPARE X36125
- VOLVO 22175635
- WAI 50-8435
- IS0842
- MS 232
