Letrika MS355 - Starter 12V, 11T, CW, Letrika/MAHLE AZJ, 3.1kW
$42599
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
LETRIKA part description
Technical Data
| Product | Starter |
| Letrika P/N | IS0705 |
| Voltage | 12 V |
| Power | 3.1 kW |
| OEM P/N | 11.130.705 |
| MAHLE P/N | MS 355 |
| Description | AZJ3243 |
| No. of pinion teeth | 11 |
| Module | 3 mm |
| Distance over two teeth | 14.39 mm |
| Outside diameter of pinion | 41 mm |
| Notes | We recommend using the Reduction Gear version IS1384 |
| Letrika P/N | OEM P/N | MAHLE P/N | |
|---|---|---|---|
| IS0705 | 11.130.705 AZJ3243 12V 3,1kW | MS 355 | Available |
Related Parts
| Letrika P/N | MAHLE P/N | DESCRIPTION | POS |
|---|---|---|---|
| 16.906.265 | MSX 117 | Brush holder | 13 |
| 16.906.267 | MSX 1241 | Fixing set | 11 |
| 16.281.921 | MSX 1278 | Drive end bracket | 1 |
| 16.905.754 | MSX 174 | Switch | 4 |
| 16.906.266 | MSX 208 | Set of brushes | 14 |
| 16.905.853 | MSX 370 | Lever | 7 |
| 16.281.299 | MSX 379 | Central cover | 3 |
| 16.901.752 | MSX 667 | Pinion with clutch | 6 |
| 15.120.243 | MSX 684 | Bearing | 2 |
| 15.120.155 | MSX 697 | Bearing | 10 |
| 16.361.527 | MSX 768 | Armature | 9 |
| 16.906.264 | MSX 780 | Stator | 12 |
| 16.906.643 | MSX 804 | Rear-end bracket | 15 |
LETRIKA MS355 Cross Reference
We have 10 alternatives for the MS355 by LETRIKA:
