Letrika MS428 - Starter 24V, 10T, CW, PLGR, Letrika/MAHLE AZE65, 3kW, New
$42899
MSRP: $592.42
Save: $163.43
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
LETRIKA part description
Technical Data
| Product | Starter |
| Letrika P/N | IS1252 |
| Voltage | 24 V |
| Power | 3.0 kW |
| OEM P/N | 11.131.861 |
| MAHLE P/N | MS 428 |
| Description | AZE6551 |
| No. of pinion teeth | 10 |
| Module | 2.54 mm |
| Distance over two teeth | 12.29 mm |
| Outside diameter of pinion | 38 mm |
| Notes | Dust-proof |
| Off set drive end bracket | |
| With reduction gear |
| Letrika P/N | OEM P/N | MAHLE P/N | |
|---|---|---|---|
| IS1252 | 11.131.861 AZE6551 24V 3,0kW | MS 428 | Available |
| IS1252 | 11.131.459 AZE6510 24V 3,0kW | Superseded unit, see available P/N IS1252 | |
| IS1252 | 11.131.395 AZE6504 24V 3,0kW | Superseded unit, see available P/N IS1252 | |
| IS1252 | 11.131.305 AZE2167 24V 2,5kW | Superseded unit, see available P/N IS1252 |
Related Parts
| Letrika P/N | MAHLE P/N | DESCRIPTION | POS |
|---|---|---|---|
| 16.915.374 | MSX 1043 | Switch | 4 |
| 16.286.084 | MSX 1152 | Stator | 12 |
| 16.916.382 | MSX 1222 | Reduction gear | 8 |
| 16.907.322 | MSX 1303 | Set of brushes | 14 |
| 16.907.409 | MSX 1347 | Brush holder | 13 |
| 15.421.663 | MSX 558 | Lever | 7 |
| 16.911.688 | MSX 570 | Pinion with clutch | 6 |
| 16.285.409 | MSX 571 | Drive end bracket | 1 |
| 15.120.182 | MSX 669 | Bearing | 2 |
| 16.907.802 | MSX 902 | Fixing set | 11 |
| 16.907.818 | MSX 915 | Armature | 9 |
| 16.285.410 | MSX 993 | Rear-end bracket | 15 |
LETRIKA MS428 Cross Reference
We have 6 alternatives for the MS428 by LETRIKA:
