Weatherhead 43016U-616 - Industrial Fitting - Hose End (Permanent) R12 Straight Female SAE37 Swivel
- Part Number
- 43016U-616
- Manufacturer
- WEATHERHEAD
- Description
-
Industrial Fitting - Hose End (Permanent) R12 Straight Female SAE37 Swivel
details
$2899
MSRP: $38.73
Save: $9.74
In stock
limited availability at this price!
. Learn more
WEATHERHEAD part description
Product Specifications
| End Size | 16 |
| End Type | SAE 37 Degree |
| Hose Family | 4-Spiral |
| Hose Size | 16 |
| Material | Carbon Steel |
| Product Line | Industrial |
| Shape | Straight |
| Style | Permanent |
| A | 4.27 |
| Application | Very high pressure hydraulic lines subjected to pressure surges and flexing. Some applications include mining, construction, farming, and high performance industrial equipment. |
| Assembly Style | 430 'U' Series |
| Description | JIC 37 Female Swivel |
| Family | Coll-O-Crimp |
| Hex "E" | 1.25 |
| Hex "F" | 1.5 |
| Hole Dia | 0.81 |
| Hole Dia. | 0.81 |
| Hose Cut-Off Factor "D" | 2.25 |
| Hose Cutt off Factor | 2.25 |
| Hose I.D. | 1 |
| Hose ID | 1 |
| Overall Length "A" | 4.27 |
| Plating | Zinc; yellow dichromate finish |
| Product Type | Fitting |
| Series | 430 'U' Series |
| Thread Size | 1 5/16-12 |
| Tube Size | 16 |
Notes
1) Exception Noted.
Eaton Weatherhead Industrial Fitting
The Eaton Weatherhead industrial fitting is durably built by experts to deliver outstanding performance in heavy-duty industrial equipment. It is also designed to work well in farming, construction, and mining applications.
Features & Benefits
- Premium-quality Coll-O-Crimp® 4-spiral industrial hose fitting
- Carbon steel construction with zinc dichromate finish for excellent corrosion resistance
- Meticulously tested to withstand high pressures and ensure leak-free performance
- Ideal for high-pressure hydraulic lines that are subjected to flexing and pressure surges
WEATHERHEAD 43016U-616 Cross Reference
We have 1 alternatives for the 43016U-616 by WEATHERHEAD:
Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
