Name: National Seals 99233 Shaft Repair Sleeve
SKU: 99233
Price: 60.99 USD
Availability: InStock

FEDERAL MOGUL-NATIONAL SEALS part description

National® has built a reputation as one of the most respected names in the industry. We have offered premium sealing solutions for more than 75 years. Our design team keeps pace with the industry and provides advanced solutions for today’s vehicles.

Designed to repair damaged, grooved or worn shafts

Durable stainless steel construction for corrosion-free sealing surface that surpasses most original shaft specifications

Ideal for a shaft where indications of seal wear, such as tracks or grooves have developed

Ultra-thin construction (0.01/0.25mm wall thickness) allows original seal size to be used with minimal additional lip loading

Easy to install with removable flange and installation tool

Installation tool reduces sleeve distortion and allows for installation without removal from the shaft

REDI-SLEEVE Shaft Size (Inch) 2.330 Shaft Size (MM) 59.182 Shaft Size Minimum (Inch) 2.327 Shaft Size Minimum (MM) 59.110 Shaft Size Maximum (Inch) 2.333 Shaft Size Maximum (MM) 59.260 Width on Shaft (Inch) 0.750 Width on Shaft (MM) 19.050 Overall Width (Inch) 0.875 Overall Width (MM) 22.230 Flanged Outside Diameter (Inch) 2.750 Flanged Outside Diameter (MM) 69.850 Installation Depth (Inch) 1.610 Installation Depth (MM) 40.890 Material Stainless Steel Unit of Dimension Inch

Product Description

Redi-sleeve

Application Summary

1972-1979 Excalibur Phaeton (Front); 1992-2001 AM General Hummer (Front); 1997-1998 Chevrolet B7 (Front); 1963-1972 Chevrolet Biscayne (Front); 1969-1972 Chevrolet Brookwood (Front); 1968-1974 Chevrolet C10 Pickup (Front); 1968-1974 Chevrolet C20 Pickup (Front); 1968-1974 Chevrolet C30 Pickup (Front); 1968 Chevrolet Chevy II (Front); 1973-1974 Chevrolet G10 Van (Front); 1973-1974 Chevrolet G30 Van (Front); 1968-1974 Chevrolet K10 Pickup (Front); 1968-1974 Chevrolet K20 Pickup (Front); 1968-1974 Chevrolet K30 Pickup (Front); 1969-1972 Chevrolet Kingswood (Front); 1970-1973 Chevrolet P20 Van (Front); 1970-1974 Chevrolet P30 Van (Front); 1969-1972 Chevrolet Townsman (Front); 1969-1970 Chevrolet Estate (Front); 1965-1973 Chevrolet Chevelle (Front); 1973-1974 Chevrolet G20 Van (Front); 1973 Chevrolet P10 Van (Front); 1991-2002 Chevrolet C3500HD (Front); 1963-1975 Chevrolet Bel Air (Front); 1973-1994 Chevrolet Blazer (Front); 1976-1986 Chevrolet K5 Blazer (Front); 1975-1986 Chevrolet C10 (Front); 1968-1986 Chevrolet C10 Suburban (Front); 1988-1998 Chevrolet C1500 (Front); 1995-1999 Chevrolet C1500 Suburban (Front); 1975-1986 Chevrolet C20 (Front); 1968-1986 Chevrolet C20 Suburban (Front); 1988-2000 Chevrolet C2500 (Front); 1992-1999 Chevrolet C2500 Suburban (Front); 1975-1986 Chevrolet C30 (Front); 1988-2000 Chevrolet C3500 (Front); 1967-1972 Chevrolet Camaro (Front); 1966-1976 Chevrolet Caprice (Front); 1965-1974 Chevrolet Corvette (Front); 1966-1975 Chevrolet El Camino (Front); 1996-2002 Chevrolet Express 2500 (Front); 1976-1995 Chevrolet G20 (Front); 1996-2002 Chevrolet Express 3500 (Front); 1975-1996 Chevrolet G30 (Front); 1963-1976 Chevrolet Impala (Front); 1976-1986 Chevrolet K10 (Front); 1968-1986 Chevrolet K10 Suburban (Front); 1988-1998 Chevrolet K1500 (Front); 1995-1999 Chevrolet K1500 Suburban (Front); 1976-1986 Chevrolet K20 (Front); 1968-1986 Chevrolet K20 Suburban (Front); 1988-2000 Chevrolet K2500 ...

Features & Benefits

Designed to repair damaged, grooved or worn shafts
Durable stainless steel construction for corrosion-free sealing surface that surpasses most original shaft specifications
Ideal for a shaft where indications of seal wear, such as tracks or grooves have developed
Ultra-thin construction (0.01/0.25mm wall thickness) allows original seal size to be used with minimal additional lip loading
Easy to install with removable flange and installation tool
Installation tool reduces sleeve distortion and allows for installation without removal from the shaft

Product Attributes

Flanged Outside Diameter (inch)	2.750 IN
Flanged Outside Diameter (mm)	69.850 MM
Installation Depth (inch)	1.610 IN
Installation Depth (mm)	40.890 MM
Material	Stainless Steel
Overall Width (inch)	0.875 IN
Overall Width (mm)	22.230 MM
Part Description	Redi-Sleeve
Product Description	Repair Sleeve
Shaft Size (inch)	2.330 IN
Shaft Size (mm)	59.182 MM
Shaft Size Maximum (inch)	2.333 IN
Shaft Size Maximum (mm)	59.260 MM
Shaft Size Minimum (inch)	2.327 IN
Shaft Size Minimum (mm)	59.110 MM
Unit of Dimension	Inch
Width On Shaft (inch)	0.750 IN
Width On Shaft (mm)	19.050 MM

Additional Information

Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	7307290090
Harmonized Tariff Code (HTS)	7307290090
UPC	00724956213801

Part Interchanges

Fits Vehicles

GMC Yukon (1994-1997)
GMC V3500 (1987-1991)
GMC V2500 Suburban (1987-1991)
GMC V2500 (1987)
GMC V1500 Suburban (1987-1991)
GMC V1500 (1987)
GMC R3500 (1987-1991)
GMC R2500 Suburban (1987-1991)
GMC R2500 (1987-1989)
GMC R1500 Suburban (1987-1991)
GMC R1500 (1987)
GMC P3500 (1979-1999)
GMC P35 (1975-1978)
GMC P2500 (1982-1989)
GMC P1500 (1979)
GMC K3500 (1979-1986, 1988-2000)
GMC K2500 Suburban (1982-1986, 1992-1999)
GMC K25 Suburban (1976-1977)
GMC K2500 (1982-1986, 1988-2000)
GMC K25 (1976-1978)
GMC K1500 Suburban (1982-1986, 1995-1999)
GMC K1500 (1980, 1982-1986, 1988-1998)
GMC K15 (1976)
GMC Savana 3500 (1996-2002)
GMC G3500 (1983-1996)
GMC G35 (1976)
GMC Savana 2500 (1996-2002)
GMC G2500 (1983-1995)
GMC G25 (1975-1976)
GMC C3500 (1979-1986, 1988-2000)
GMC C35 (1975-1978)
GMC C2500 Suburban (1979-1986, 1992-1999)
GMC C25 Suburban (1975-1978)
GMC C2500 (1979-1986, 1988-2000)
GMC C25 (1975-1978)
GMC C1500 Suburban (1979-1980, 1982-1986, 1995-1999)
GMC C15 Suburban (1975-1978)
GMC C1500 (1979-1980, 1982-1986, 1988-1997)
GMC C15 (1975-1978)
Chevrolet V3500 (1989-1991)
Chevrolet V30 (1987-1988)
Chevrolet V2500 Suburban (1989-1991)
Chevrolet V20 Suburban (1987-1988)
Chevrolet V20 (1987)
Chevrolet V1500 Suburban (1989-1991)
Chevrolet V10 Suburban (1987-1988)
Chevrolet V10 (1987)
Chevrolet Tahoe (1995-1999)
Chevrolet R3500 (1989-1991)
Chevrolet R30 (1987-1988)
Chevrolet R2500 Suburban (1989-1991)
Chevrolet R2500 (1989)
Chevrolet R20 Suburban (1987-1988)
Chevrolet R20 (1987-1988)
Chevrolet R1500 Suburban (1989-1991)
Chevrolet R10 Suburban (1987-1988)
Chevrolet R10 (1987)
Chevrolet P30 (1975-1999)
Chevrolet P20 (1976, 1979, 1982-1989)
Chevrolet K3500 (1988-2000)
Chevrolet K30 (1977, 1980-1986)
Chevrolet K2500 Suburban (1992-1999)
Chevrolet K2500 (1988-2000)
Chevrolet K20 (1976-1978, 1982-1986)
Chevrolet K1500 Suburban (1995-1999)
Chevrolet K1500 (1988-1998)
Chevrolet K10 (1976, 1980, 1982-1986)
Chevrolet G30 (1975-1976, 1983-1996)
Chevrolet G20 (1976, 1983-1995)
Chevrolet Express 3500 (1996-2002)
Chevrolet Express 2500 (1996-2002)
Chevrolet C3500 (1988-2000)
Chevrolet C30 (1975-1986)
Chevrolet C2500 Suburban (1992-1999)
Chevrolet C2500 (1988-2000)
Chevrolet C20 (1975-1986)
Chevrolet C1500 Suburban (1995-1999)
Chevrolet C1500 (1988-1998)
Chevrolet C10 (1975-1980, 1982-1986)
Chevrolet K5 Blazer (1976-1978, 1982-1986)
AM General Hummer (1992-2001)
GMC C3500HD (1991-2002)
Chevrolet C3500HD (1991-2002)
Workhorse FasTrack FT1802 (2002-2003)
Workhorse FasTrack FT1801 (2002-2005)
Workhorse P42 (1999-2005)
Workhorse P32 (1999-2000)
Chevrolet Estate (1969-1970)
Pontiac Parisienne (1966-1970)
Pontiac Laurentian (1966-1970)
Pontiac Strato-Chief (1965-1970)
Pontiac Beaumont (1965-1969)
GMC B7 (1997-1998)
Chevrolet B7 (1997-1998)
Iso Grifo (1969-1974)
Pontiac Acadian (1968-1971)
Hummer H1 (2002-2004)
GMC Sprint (1971-1975)
GMC P35/P3500 Van (1970-1971, 1973-1974)
GMC P25/P2500 Van (1970-1971)
GMC K35/K3500 Pickup (1970-1974)
GMC K25/K2500 Suburban (1968-1974)
GMC K25/K2500 Pickup (1968-1974)
GMC K15/K1500 Suburban (1968-1974)
GMC K15/K1500 Pickup (1968-1974)
GMC Jimmy (1973-1974, 1976, 1982-1991)
GMC G35/G3500 Van (1973-1974)
GMC C35/C3500 Pickup (1968-1974)
GMC C25/C2500 Suburban (1968-1974)
GMC C25/C2500 Pickup (1968-1974)
GMC C15/C1500 Suburban (1968-1974)
GMC C15/C1500 Pickup (1968-1974)
Excalibur Phaeton (1972-1979)
Chevrolet Townsman (1969-1972)
Chevrolet P30 Van (1970-1974)
Chevrolet P20 Van (1970-1971, 1973)
Chevrolet P10 Van (1973)
Chevrolet Nova (1969-1972)
Chevrolet Monte Carlo (1970-1975)
Chevrolet Malibu (1965-1967, 1973-1975)
Chevrolet Laguna (1973-1975)
Chevrolet Kingswood (1969-1972)
Chevrolet K30 Pickup (1968-1974)
Chevrolet K20 Suburban (1968-1974, 1982-1986)
Chevrolet K20 Pickup (1968-1974)
Chevrolet K10 Suburban (1968-1974, 1982-1986)
Chevrolet K10 Pickup (1968-1974)
Chevrolet Impala (1963, 1965-1976)
Chevrolet G30 Van (1973-1974)
Chevrolet G20 Van (1973-1974)
Chevrolet G10 Van (1973-1974)
Chevrolet El Camino (1966-1975)
Chevrolet Corvette (1965-1974)
Chevrolet Chevy II (1968)
Chevrolet Chevelle (1965-1973)
Chevrolet Caprice (1966-1976)
Chevrolet Camaro (1967-1972)
Chevrolet C30 Pickup (1968-1974)
Chevrolet C20 Suburban (1968-1986)
Chevrolet C20 Pickup (1968-1974)
Chevrolet C10 Suburban (1968-1980, 1982-1986)
Chevrolet C10 Pickup (1968-1974)
Chevrolet Brookwood (1969-1972)
Chevrolet Blazer (1973-1974, 1987-1991, 1994)
Chevrolet Biscayne (1963, 1965-1972)
Chevrolet Bel Air (1963, 1965-1975)
Avanti II (1973-1976)

The National Seals® is a proud designer and supplier of wheel bearings and oil seals with a focus on quality, safety, and continuous improvement. The key to its success may be attributed to its hardworking and dedicated team of engineers who keep pace with the industry to provide premium wheel end solutions for light and commercial vehicle applications. Federal-Mogul acquired the National Seal Division of the National Motor Bearing Company only in 1942. But the brand National Seals has already cemented itself as one of the most respected names in the industry. Over the years, it has remained fully committed to providing only the highest quality seals and bearings that meet or exceed OE specifications.
