Name: National Seals 472705 Man Trans Seal
SKU: 472705
Price: 9.99 USD
Availability: InStock

FEDERAL MOGUL-NATIONAL SEALS part description

Description

National® has built a reputation as one of the most respected names in the industry. We have offered premium sealing solutions for more than 70 years. Our design team keeps pace with the industry and provides advanced solutions for today™s vehicles. : • National® oil seals are recognized worldwide for their quality and reliable performance for every type of repair.

• Design Type: Spring Loaded; Multi-Lip

• Provides good low temperature capability

• Low swell in hydrocarbon fluids

• Temperature Range: -40°F to 225°F; -40°C to 107°C

• Products sold are warranted to be free from defects in workmanship or material for a period of one (1) year from the date of purchase.
Specifications

OIL SEAL: Part Description: Oil Seal

Shaft (Inch): 0.562

Shaft (MM): 14.270

Housing Bore (Inch): 1.000

Housing Bore (MM): 25.400

Outside Diameter (Inch): 1.004

Outside Diameter (MM): 25.500

Width (Inch): 0.250

Width (MM): 6.350

Material: Nitrile

Type: 47

Footnote: Zero Duplication Part

Series: 470000

Redicoat: Yes
Applications

PASSENGER CAR & LIGHT TRUCK

Chevrolet Corvair 1969-1960

Chevrolet Corvair Truck 1964-1961

Pontiac Tempest 1963-1961

Product Description

Man Trans Shift Shaft Seal

Application Summary

1960-1969 Chevrolet Corvair (Transmission Base Gear: 3, 4 & Transmission Control Type: Manual / Qualifier: with GMC Saginaw Transmission, Nitrile, 4 Speed, 3 Speed); 1961-1964 Chevrolet Corvair Truck (Transmission Base Gear: 3, 4 & Transmission Control Type: Manual / Qualifier: with GMC Saginaw Transmission, Nitrile); 1961-1963 Pontiac Tempest (Transmission Base Gear: 4, 3 & Transmission Control Type: Manual / Qualifier: with GMC Saginaw Transmission, Nitrile)

Features & Benefits

Design type: spring loaded; multi-lip
Temperature range: -40degF to 225degF / -40degC to 107degC
Good low temperature capability
Low swell in hydrocarbon fluids
Delivers quality and reliable performance for every type of repair

Product Attributes

Inside Diameter	0.562 IN
Thickness	0.250 IN
Outside Diameter	1.004 IN
Sealing Material	Nitrile
Footnote	Zero Duplication Part
Housing Bore (inch)	1.000 IN
Housing Bore (mm)	25.400 MM
Material	Nitrile
Outside Diameter (inch)	1.004 IN
Outside Diameter (mm)	25.500 MM
Part Description	Oil Seal
Redicoat	Yes
Series	470000
Shaft (inch)	0.562 IN
Shaft (mm)	14.270 MM
Type	47
Unit of Dimension	Inch
Width (inch)	0.250 IN
Width (mm)	6.350 MM

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	4016931020
Harmonized Tariff Code (HTS)	4016931020
UPC	00724956140541

Part Interchanges

Fits Vehicles

Pontiac Tempest (1961-1963)
Chevrolet Corvair Truck (1961-1964)
Chevrolet Corvair (1960-1969)

The National Seals® is a proud designer and supplier of wheel bearings and oil seals with a focus on quality, safety, and continuous improvement. The key to its success may be attributed to its hardworking and dedicated team of engineers who keep pace with the industry to provide premium wheel end solutions for light and commercial vehicle applications. Federal-Mogul acquired the National Seal Division of the National Motor Bearing Company only in 1942. But the brand National Seals has already cemented itself as one of the most respected names in the industry. Over the years, it has remained fully committed to providing only the highest quality seals and bearings that meet or exceed OE specifications.
