Name: National Seals 370247A Wheel Seal
SKU: 370247a
Price: 28.49 USD
Availability: InStock

FEDERAL MOGUL-NATIONAL SEALS part description

Our National® oil bath seal boasts maximum protection and longer life under even the most grueling environmental conditions.

National® has built a reputation as one of the most respected names in the industry. We have offered premium sealing solutions for more than 70 years. Our design team keeps pace with the industry and provides advanced solutions for todays vehicles.

Temperature range: -40°F to 225°F: -40°C to 107°C
Unitized construction provides greater structural integrity, easier installation and main lip protection
Abrasion resistant nitrile with spring-loaded main lip for positive sealing with reduced shaft interference
Unique rubber I.D. and O.D. includes patented SURE-LOCK® ribs that prevent shaft leaks and bore contamination
Red 37 Series oil bath seals delivers a dependable point contact seal

Part Specifications

NATIONAL OIL SEAL SPECS

Part Description	Oil Bath Seal
Shaft (Inch)	2.955
Shaft (MM)	75.060
Housing Bore (Inch)	3.875
Housing Bore (MM)	98.430
Outside Diameter (Inch)	3.882
Outside Diameter (MM)	98.600
Width (Inch)	0.488
Width (MM)	12.400
Material	Nitrile
Type	#
Footnote	Spindle Mount
Series	Gold 38 Series
Installation Tool	RD306
Redicoat	Yes

Product Description

Oil Bath Seal

Application Summary

2015-2018 Ford Transit-150 (Rear Inner) (Qualifier: with Single Rear Wheels (SRW)); 2015-2019 Ford Transit-250 (Rear Inner) (Qualifier: with Single Rear Wheels (SRW)); 2015-2019 Ford Transit-350 (Rear Inner) (Qualifier: with Single Rear Wheels (SRW)); 2015-2019 Ford Transit-350 HD (Rear Inner) (Qualifier: with Single Rear Wheels (SRW)); 2000-2005 Ford Excursion (Rear Inner); 1999-2019 Ford F-250 Super Duty (Rear Inner); 1999-2019 Ford F-350 Super Duty (Rear Inner) (Qualifier: with 10.5 (in) Ring Gear, with Single Rear Wheels (SRW))

Features & Benefits

Red 37 Series oil bath seals deliver dependable point contact seal
Temperature range: -40degF to 225degF; -40degC to 107degC
Unitized construction provides greater structural integrity, easier installation and main lip protection
Abrasion-resistant nitrile with spring-loaded main lip for positive sealing with reduced shaft interference
Unique rubber I.D. and O.D. includes patented SURE-LOCK(R) ribs that prevent shaft leaks and bore contamination

Product Attributes

Material	Nitrile
Width	0.488 IN
Outside Diameter	3.882 IN
Shaft Diameter	2.955 IN
Housing Bore	3.875 IN
Housing Bore (inch)	3.875 IN
Housing Bore (mm)	98.430 MM
Installation Tool	RD247
Outside Diameter (inch)	3.882 IN
Outside Diameter (mm)	98.600 MM
Part Description	Oil Bath Seal
Series	370000
Shaft (inch)	2.955 IN
Shaft (mm)	75.060 MM
Type	#
Unit of Dimension	Inch
Width (inch)	0.488 IN
Width (mm)	12.400 MM

Additional Information

Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	4016931020
Harmonized Tariff Code (HTS)	4016931020
UPC	00614046722521

Part Interchanges

Fits Vehicles

Ford Transit-350 HD (2015-2019)
Ford Transit-150 (2015-2018)
Ford Transit-250 (2015-2019)
Ford Transit-350 (2015-2019)
Ford F-350 Super Duty (1999-2019)
Ford F-250 Super Duty (1999-2019)
Ford Excursion (2000-2005)
