Name: National Seals 1213N Oil Seal
SKU: 1213n
Price: 9.49 USD
Availability: InStock

FEDERAL MOGUL-NATIONAL SEALS part description

Description

National® has built a reputation as one of the most respected names in the industry. We have offered premium sealing solutions for more than 70 years. Our design team keeps pace with the industry and provides advanced solutions for today™s vehicles. : • National® oil seals are recognized worldwide for their quality and reliable performance for every type of repair.

• Design Type: Spring Loaded; Multi-Lip

• Compatible with most oils and EP lubricants at higher operating temperatures

• High resistance to oxidation and ozone and has low swell in hydrocarbon fluids

• Temperature Range: -20°F to 300°F; -29°C to `49°C

• Products sold are warranted to be free from defects in workmanship or material for a period of one (1) year from the date of purchase.
Specifications

OIL SEAL: Part Description: Oil Seal

Shaft (Inch): 1.575

Shaft (MM): 40.000

Housing Bore (Inch): 2.126

Housing Bore (MM): 54.000

Outside Diameter (Inch): 2.130

Outside Diameter (MM): 54.100

Width (Inch): 0.217

Width (MM): 5.500

Material: Polyacrylate

Type: 47

Series: 1000

Redicoat: Yes
Applications

PASSENGER CAR & LIGHT TRUCK

Asuna Sunrunner 1993-1992

Chevrolet Tracker 2004-1989

Ford Taurus 1995-1989

Geo Tracker 1997-1989

GMC Tracker 1991-1989

Mazda 1200 1971-1970

Mazda 1800 1971-1970

Mazda 616 1971-1970

Mazda 618 1972

Mazda 626 1982-1979

Mazda 808 1977-1972

Mazda Mizer 1977-1976

Mazda R100 1972-1970

Mazda RX-2 1974-1970

Mazda RX-3 1978-1972

Mazda RX-4 1978-1974

Mazda RX-7 1985-1979

Mercury Capri 1994-1991

Pontiac Sunrunner 1997-1994

Suzuki Grand Vitara 2005-1999

Suzuki Sidekick 1998-1989

Suzuki Vitara 2003-1999

Suzuki X-90 1998-1996

Product Description

Oil Seal

Application Summary

1999-2005 Suzuki Grand Vitara (Front, Rear Outer) (Drive: 4WD, AWD / Qualifier: with Suzuki G130 Transfer Case, with Part Time 4WD, 2 Speed); 1989-1998 Suzuki Sidekick (Rear Outer, Front) (Drive: 4WD / Qualifier: with Suzuki G130 Transfer Case, with Part Time 4WD, 2 Speed); 1999-2004 Suzuki Vitara (Rear Outer, Front) (Drive: 4WD / Qualifier: with Suzuki G130 Transfer Case, with Part Time 4WD, 2 Speed); 1996-1998 Suzuki X-90 (Front, Rear Outer) (Drive: 4WD / Qualifier: with Suzuki G130 Transfer Case, with Part Time 4WD, 2 Speed); 1989-2004 Chevrolet Tracker (Rear Outer, Front) (Drive: 4WD / Qualifier: with Suzuki G130 Transfer Case, with Part Time 4WD, 2 Speed); 1989-1991 GMC Tracker (Rear Outer, Front) (Drive: 4WD / Qualifier: with Suzuki G130 Transfer Case, with Part Time 4WD, 2 Speed); 1989-1997 Geo Tracker (Rear Outer, Front) (Drive: 4WD / Qualifier: with Suzuki G130 Transfer Case, with Part Time 4WD, 2 Speed); 1994-1997 Pontiac Sunrunner (Rear Outer, Front) (Drive: 4WD / Qualifier: with Suzuki G130 Transfer Case, with Part Time 4WD, 2 Speed); 1991-1994 Mercury Capri (Rear Inner); 1972-1977 Mazda 808 (Front Inner); 1972-1978 Mazda RX-3 (Front Inner); 1979-1985 Mazda RX-7 (Front Inner); 1974-1978 Mazda RX-4 (Front Inner); 1970-1972 Mazda R100 (Front Inner); 1970-1972 Mazda 616 (Front Inner); 1972-1973 Mazda 618 (Front Inner); 1971-1974 Mazda RX-2 (Front Inner); 1979-1982 Mazda 626 (Front Inner); 1976-1977 Mazda Mizer (Front Inner); 1970-1972 Mazda 1200 (Front Inner); 1970-1971 Mazda 1800 (Front Inner)

Features & Benefits

Design type: spring loaded; multi-lip
Temperature range: -20degF to 300degF / -29degC to 49degC
Resistance to EP lubricants
Low swell in hydrocarbon fluids
Delivers quality and reliable performance for every type of repair

Product Attributes

Material	Polyacrylate
Inside Diameter	1.575 IN
Thickness	0.217 IN
Outside Diameter	2.130 IN
Sealing Material	Polyacrylate
Housing Bore (inch)	2.126 IN
Housing Bore (mm)	54.000 MM
Outside Diameter (inch)	2.130 IN
Outside Diameter (mm)	54.100 MM
Part Description	Oil Seal
Redicoat	Yes
Series	1000
Shaft (inch)	1.575 IN
Shaft (mm)	40.000 MM
Type	47
Unit of Dimension	Metric
Width (inch)	0.217 IN
Width (mm)	5.500 MM

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	4016931020
Harmonized Tariff Code (HTS)	4016931020
UPC	00087674968560

Part Interchanges

Fits Vehicles

Mercury Capri (1991-1994)
Geo Tracker (1989-1997)
Suzuki X-90 (1996-1998)
Suzuki Sidekick (1989-1998)
Mazda 1800 (1970-1971)
Mazda 1200 (1970-1972)
GMC Tracker (1989-1991)
Suzuki Vitara (1999-2004)
Suzuki Grand Vitara (1999-2005)
Chevrolet Tracker (1989-1991, 1998-2004)
Mazda 626 (1979-1982)
Mazda Mizer (1976-1977)
Mazda RX-2 (1971-1974)
Mazda R100 (1970-1972)
Mazda 618 (1972-1973)
Mazda 616 (1970-1972)
Pontiac Sunrunner (1994-1997)
Mazda RX-4 (1974-1978)
Mazda RX-7 (1979-1985)
Mazda RX-3 (1972-1978)
Mazda 808 (1972-1977)

The National Seals® is a proud designer and supplier of wheel bearings and oil seals with a focus on quality, safety, and continuous improvement. The key to its success may be attributed to its hardworking and dedicated team of engineers who keep pace with the industry to provide premium wheel end solutions for light and commercial vehicle applications. Federal-Mogul acquired the National Seal Division of the National Motor Bearing Company only in 1942. But the brand National Seals has already cemented itself as one of the most respected names in the industry. Over the years, it has remained fully committed to providing only the highest quality seals and bearings that meet or exceed OE specifications.
