Name: Monroe 65416 Magnum Shock Absorber - 17.75 in. Extended Length, Rear
SKU: 65416
Price: 61.49 USD
Availability: InStock

MONROE part description

Technical Specifications:

Series	Magnum
Location	Rear
Quantity Sold	Sold Individually
Compressed Length	11.99 in.
Extended Length	17.75 in.
Travel Length	5.76 in.
Dust Shield	Yes
Dust Shield Material	Metal
Upper Mounting Description	Loop Bushing & Sleeve Mount3/4" Sleeve ID X 1.3/4" Sleeve OAL
Lower Mounting Description	Loop Bushing & Sleeve Mount3/4" Sleeve ID X 1.3/4" Sleeve OAL
Compressed Bumper Stop	No
Extended Bumper Stop	No
Extended Hydraulic Lockout	Yes
Parts Pack	None
UPC	048598173164
VMRS Code	016008003
UNSPSC	25172011
Harmonized Tariff Code	8708801600

Application Summary

2002-1997 GMC T5500Tilt Cab Rear
2002-1997 GMC T6500 Rear
2002-1997 GMC T6500Tilt Cab Rear
2002-1997 GMC T7500 Rear
2002-1997 GMC T7500Tilt Cab Rear
2002-1997 GMC T8500Tilt Cab Rear
2002-1997 Isuzu FSR Rear

Monroe Shock Absorber

The Monroe shock absorber provides strong dampening properties for on-highway conditions. It is suitable for use with Class 7 & 8 trailers.

Features & Benefits

Self-lubricating fluid seal for a maintenance-free operation
Innovative design that retains gas without causing excessive wear or friction
Increased fluid capacity helps ensure consistent performance
Full-extension stop configuration compatible with air suspension applications

General Application

Class 7 & 8, Trailer

Product Description

Magnum Shock Absorber

Application Summary

2002-1997 GMC T5500 - Tilt Cab Rear, 2002-1997 GMC T6500 Rear, 2002-1997 GMC T6500 - Tilt Cab Rear, 2002-1997 GMC T7500 Rear, 2002-1997 GMC T7500 - Tilt Cab Rear, 2002-1997 GMC T8500 - Tilt Cab Rear, 2002-1997 Isuzu FSR Rear

Product Attributes

Compressed Length	11.99 IN
Travel Length	5.76 in
Extended Length	17.75 in
Dust Shield Material	Metal
Compressed Bumper Stop	No
Dust Shield Included	Yes
Extended Bumper Stop	No
Extended Hydraulic Lockout	Yes
Lower Mounting Code	LS54
Lower Mounting Description	Loop Bushing & Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL
Parts Pack	None
Upper Mounting Code	LS54
Upper Mounting Description	Loop Bushing & Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL

Additional Information

Country of Origin (Primary)	US
Canadian Harmonizing Tariff Code	8708803000
Harmonized Tariff Code (Schedule B)	8708801600
Harmonized Tariff Code (HTS)	8708801600
MSDS Sheet Number	01164
Refurbished Part	N
Remanufactured Part	N
UPC	00048598173164
VMRS Code	016008003
UNSPSC	25172011

Part Interchanges

MONROE 65416 Cross Reference

We have 145 alternatives for the 65416 by MONROE:

Fits Vehicles

Kenworth T600A (1986-2008)
Isuzu FVR (1997-2002)
Isuzu FTR (1997-2003)
Isuzu FSR (1997-2002)
GMC T6500 (1997-2002)
GMC T7500 (1997-2002)
