WIX FILTERS part description

Product Specifications

Part Number:	57623
UPC Number:	765809576230
Style:	Spin-On Transmission Filter
Service:	Transmission
Type:	Full Flow
Media:	Microglass
Height:	10.295 (261)*
Outer Diameter:	4.666 (119)*
Thread Size:	1 5/16-12
By-Pass Valve Setting-PSI:	None
Beta Ratio:	2/20=6/14
Burst Pressure-PSI:	580
Max Flow Rate:	40 GPM
Nominal Micron Rating:	6

( )* denotes metric

Gasket Diameters

Number	O.D.	I.D.	Thk.
Attached	4.200 (107)*	3.662 (93)*	0.415 (11)*

Principle Application:

Synthetic Media Version of 51623

Product Description

WIX Spin-On Transmission Filter

Application Summary

Synthetic Media Version of 51623

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Product Attributes

Anti-Drain Back Valve	No
BetaRatio	2/20=6/14
Burst Pressure	580 PSI
Bypass Relief Valve Setting	None
Class	HW
Duty Type	HD
Flow Rate	40 GPM GPM
Height	10.295 in
Inner Diameter Top	Closed
Media Material	Microglass
Micron	6.00 Micron
Outer Diameter Bottom	4.666 in
Outer Diameter Top	4.666 in
Style	Spin-On Transmission Filter
Thread Size	1 5/16-12 IN

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (HTS)	8421290065
Remanufactured Part	N
UPC	00765809576230

Part Interchanges

Since its establishment in 1939, the name WIX Filters® has been synonymous with a strong tradition of excellence. This brand opened its door to business in an old cotton mill in Gastonia to provide its customers with premium-quality filters that exceed their performance demands. Within 15 years since it was founded, WIX Filters have revolutionized the automotive filtration system by introducing and patenting the spin-on oil filter design called “twist of the wrist,” which quickly became the industry standard. The eight decades of growth and innovation made WIX Filters a global leader in filtration, with over 12,000 unique product numbers covering a wide range of fuel, oil, air, coolant, cabin air, and transmission filters for domestic and foreign vehicles and industrial applications and more than 8,000 part numbers for fluid power systems and hydraulic applications.
