Haldex KN33002 - Dryerpureair 12V
$54299
MSRP: $1,231.76
Save: $688.77
In stock
limited availability at this price!
. Learn more
HALDEX part description
HALDEX PURE AIR™ AIR DRYER
Pure Air™ Air Dryer - Compact Size- Compact size.
- Triple action - cools, filters and dries the air.
- May be mounted vertically or horizontally.
- Serviceable from either end.
Technical Specifications:
| Heater Voltage: | 12 Volts |
| Inlet Port: | 1/2" |
| Outlet Port: | 1/2" |
| Governor Port: | 1/8" |
| Exhaust Port: | 1" Hose |
| Approximate Weight: | 18.6 lbs. |
| OEM Part Number: | N4245 |
| Length: | 12" |
| Maximum Width: | 7.49" |
| Heater: | 60 Watt Thermostatic |
| Primary Material: | Aluminum |
| Drying Method: | Coalescence/Desiccant |
| Mounting: | Horizontal or Vertical |
| Burst Rating: | 500 PSI |
| Max. Compressor Capacity: | 24 SCFM |
| Air Ports: | 1/2" Pipe |
Haldex Pure Air™ Air Brake Dryer
Prevent air-line freeze-ups with the Haldex Pure Air™ air brake dryer. Manufactured by a brand with more than 100 years of engineering expertise, this air dryer ensures only clean, dry air is being supplied to the air brake system as it helps filter most liquid and water vapor from the compressor discharge air.
Features & Benefits
- Engineered using state-of-the-art technology for maximum efficiency
- Boasts triple-action—cooling, filtering, and drying the air
- Has a standard size and offers ease of installation
- Built to offer flexibility since air dryer may be mounted horizontally or vertically
- Can be serviced from either end
- All Haldex air dryers are manufactured to meet the highest quality standards
Product Description
Pure Air™ Air Dryer - Compact Size, 12V
Features & Benefits
- Engineered using state-of-the-art technology for maximum efficiency
- Boasts triple-action—cooling, filtering, and drying the air
- Has a standard size and offers ease of installation
- Built to offer flexibility since air dryer may be mounted horizontally or vertically
- Can be serviced from either end
- All Haldex air dryers are manufactured to meet the highest quality standards
Haldex Pure Air™ Air Brake Dryer
Prevent air-line freeze-ups with the Haldex Pure Air™ air brake dryer. Manufactured by a brand with more than 100 years of engineering expertise, this air dryer ensures only clean, dry air is being supplied to the air brake system as it helps filter most liquid and water vapor from the compressor discharge air.
Product Attributes
| Air Port Thread Diameter | 1/2 in. |
| Burst Pressure | 500 PS |
| Drying Method | Coalescence/Desiccant |
| Exhaust Port Diameter | 1 in. |
| Freight Class | 70 |
| Governor Port Diameter | 1/8 in. |
| Heater Included | Yes |
| Heater Voltage | 12V |
| Inlet Port Diameter | 1/2 in. |
| Length | 12 in. |
| Material | Aluminum |
| Maximum Compressor Capacity | 24 SCFM |
| Mounting Bracket Included | Yes |
| Mounting Position | Horizontal or Vertical |
| New Or Remanufactured | New |
| Outlet Port Diameter | 1/2 in. |
| Port Quantity | 4 |
| Series | Pure Air™ |
| Wattage | 60 Watts |
| Width | 7.49 in. |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8421398015 |
| Harmonized Tariff Code (HTS) | 8421398015 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | See Haldex Aftermarket Product warranty Policy (L20221W).pdf |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653011202 |
| VMRS Code | 013010252 |
Part Interchanges
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
