Name: Haldex KN28602 Full Func Trail Vlv
SKU: kn28602
Price: 137.49 USD
Availability: InStock

HALDEX part description

HALDEX TRAILER VALVE

FF2 - Full Function Trailer Valve

Single valve system - easy to install, maintain and troubleshoot.
Built-in pressure protection and anti-compounding functions: FMVSS-121 compliant, eliminates broken foundation components caused by compounding of spring brake.
Space age engineering grade composites: resists corrosion, lighter and more durable than aluminum.
Built-in service and spring brake quick release.
Heavy wall mounting nipple is treated to resist corrosion and withstand severe duty applications.
Service brake priority ensures air tank pressure is sufficient to stop vehicle when spring brakes are first released.
Can be used with single or twin air tanks.
Approximate Weight 3 lbs.

Technical Specifications:

Crack Pressure:	5.0 PSI
Reservoir:	3/4"
Control:	1/4"
Supply:	3/8"
Spring Brake (2):	3/8"
Delivery (4):	3/8"
OEM Part Number:	N4304AE
Approximate Weight:	3 lbs.

Product Description

FF2 - Full Function Trailer Valve

Features & Benefits

A highly reliable single valve system designed for use with single or twin air tanks
Made with space age engineering grade composites that is lighter and more durable than aluminum and resists corrosion effectively
With a heavy wall mounting nipple that is treated for lasting durability and superior corrosion resistance
All Haldex valves are designed to offer quick, trouble-free installation, repair, and maintenance

Haldex Full-Function Valve

The Haldex full-function valve is made to deliver built-in pressure protection and anti-compounding functions. This product goes through stringent manufacturing processes and testing for maximum performance and reliability.

Product Attributes

Control Port Diameter	1/4 in.
Freight Class	70
Opening Pressure	5.0 PSI
Reservoir Port Diameter	3/4 in.
Spring Brake Port Diameter	2 @ 3/8 in.
Supply Port Diameter	3/8 in.

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	8481200070
Harmonized Tariff Code (HTS)	8481200070
Remanufactured Part	N
Warranty Distance	100000
Warranty Distance UOM	MI
Warranty Special	36 MO, 350,000 MI=Haldex Air Brake Valves(1), Automatic Drain Valves (410-10XXX Series)(1). 12 MO, 100,000 MI= Automatic Drain Valves (N20878/ N20879 Series), Height Control Valve, Scale-O-Matic and AC Boxes. See L20221W.pdf for warranty details
Warranty Time	12
Warranty Time UOM	MO
UPC	00767653010847
VMRS Code	013010364

Part Interchanges

HALDEX KN28602 Cross Reference

We have 3 alternatives for the KN28602 by HALDEX:

Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
