Name: Haldex KN20612 Manifold Dash Valve
SKU: kn20612
Price: 215.49 USD
Availability: InStock

HALDEX part description

HALDEX HAND CONTROL VALVE

Manifold Dash Valve

Engineering Grade Composite (EGC) - One Piece Housing
Ports have molded identification
Completely serviceable
2 Spools

Notes:

Tractor Valve 20 - 35 PSI
Trailer Valve 20 - 45 PSI
Non-Override 25 ± 5 PSI

Technical Specifications:

Mounting (4):	Horizontal - 10-24 well nuts in body
Trailer Delivery:	1/4" in.
Reservoirs (2):	1/4" in.
Exhaust:	1/4" in.
Tractor Delivery:	1/4" in.
Auxiliary Supply:	1/4" in.
OEM Part Number:	N4400EJ - N4400A
Tractor Valve:	20 - 35 PSI
Trailer Valve:	20 - 45 PSI
Non-Override:	25 ± 5 PSI
Spools:	2

Haldex Hand Operated Valve

The Haldex hand operated valve enables the user to manually reduce incoming pressure to the desired output pressure. Manufactured by a brand with over 100 years of engineering expertise, this hand control valve delivers superior performance, reliability, and efficiency.

Product Description

Manifold Dash Valve

Features & Benefits

A completely serviceable valve designed with customer in mind
Made with Engineering Grade Composite (EGC) - one-piece housing
Built to last longer than the competing brand
A perfect replacement valve at a budget-friendly price

Haldex Hand Operated Valve

Product Attributes

Auxiliary Supply Port	.25 in.
Delivery Port Trailer	.25 in.
Exhaust Port	0.25
Freight Class	70
Mounting (4 holes)	Horizontal - 10-24 well nuts in body
Non-Override Pressure	25 ± 5 PSI
Reservoir Port	2 @ .25
Spools	2
Tractor Delivery Port	.25 in.
Tractor Valve	20 - 35 PSI
Trailer Valve	20 - 45 PSI

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	8481200070
Harmonized Tariff Code (HTS)	8481200070
Remanufactured Part	N
Warranty Distance	100000
Warranty Distance UOM	MI
Warranty Special	36 MO, 350,000 MI=Haldex Air Brake Valves(1), Automatic Drain Valves (410-10XXX Series)(1). 12 MO, 100,000 MI= Automatic Drain Valves (N20878/ N20879 Series), Height Control Valve, Scale-O-Matic and AC Boxes. See L20221W.pdf for warranty details
Warranty Time	12
Warranty Time UOM	MO
UPC	00767653010120
VMRS Code	013010050

Part Interchanges

HALDEX KN20612 Cross Reference

We have 3 alternatives for the KN20612 by HALDEX:

Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
