Haldex KN20545 - Vlvhand Cntrl
$11849
14 day lead time
limited availability at this price!
. Learn more
HALDEX part description
HALDEX HAND CONTROL VALVE
In-Column Mount Trailer Brake Control Valve- Made of durable (EGC) Engineering Grade Composite
- Handle applies 50° maximum
- Approximate Weight 0.70 lbs.
- Push-To-Connect (PTC) fittings for nylon tubing
- Handle and knob NOT supplied with service unit
- Retro-Fit Bracket use part number 102008GM
- Replacement for Haldex part number KN20545
Technical Specifications:
| Type: | Self-Releasing |
| Supply: | 3/8" PTC |
| Delivery: | 3/8" PTC |
| Exhaust: | 1/4" in. |
| Handle: | KQ205450 |
| OEM Part Number: | N30103FC |
Haldex Hand Operated Valve
The Haldex hand operated valve enables the user to manually reduce incoming pressure to the desired output pressure. Manufactured by a brand with over 100 years of engineering expertise, this hand control valve delivers superior performance, reliability, and efficiency.
Product Description
In-Column Mount Trailer Brake Control
Application Summary
Self-Releasing
Features & Benefits
- A completely serviceable valve designed with customers in mind
- Made with Engineering Grade Composite (EGC) - one-piece housing
- Built to last longer than the competing brand
- A perfect replacement valve at a budget-friendly price
Haldex Hand Operated Valve
The Haldex hand operated valve enables the user to manually reduce incoming pressure to the desired output pressure. Manufactured by a brand with over 100 years of engineering expertise, this hand control valve delivers superior performance, reliability, and efficiency.
Product Attributes
| Delivery Port Diameter | 3/8 in. PTC |
| Exhaust Port Diameter | 1/4 in. |
| Freight Class | 70 |
| Supply Port Diameter | 3/8 in. |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8481200070 |
| Harmonized Tariff Code (HTS) | 8481200070 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | 36 MO, 350,000 MI=Haldex Air Brake Valves(1), Automatic Drain Valves (410-10XXX Series)(1). 12 MO, 100,000 MI= Automatic Drain Valves (N20878/ N20879 Series), Height Control Valve, Scale-O-Matic and AC Boxes. See L20221W.pdf for warranty details |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653110271 |
| VMRS Code | 013010014 |
Part Interchanges
HALDEX KN20545 Cross Reference
We have 2 alternatives for the KN20545 by HALDEX:
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
