Name: Haldex KN20541 Vlvhand Cntrl
SKU: kn20541
Price: 73.99 USD
Availability: InStock

HALDEX part description

HALDEX HAND CONTROL VALVE

In-Column Mount Trailer Brake Control Valve

Made of durable EGC (Engineering Grade Composite)
Handle applies 50° maximum
Approximate Weight 0.70 lbs.

Notes

Available with Push-To-Connect (PTC) fittings for nylon tubing, order KN20548
Handle and knob NOT supplied with service unit
Retro-Fit Bracket use part number 102008GM

Technical Specifications:

Type:	Holding
Supply:	1/4" in.
Delivery:	1/4" in.
Exhaust:	1/4" in.
Handle:	KN20543
OEM Part Number:	N30103BB
Approximate Weight`:	0.70 lbs.

Haldex Hand Operated Valve

The Haldex hand operated valve enables the user to manually reduce incoming pressure to the desired output pressure. Manufactured by a brand with over 100 years of engineering expertise, this hand control valve delivers superior performance, reliability, and efficiency.

Features & Benefits

A highly reliable in-column mount trailer brake control valve
Made of Engineering Grade Composite (EGC) that is proven tough, light, and corrosion resistant
For this valve, handle applies 50° maximum
Comes with push-to-connect (PTC) fittings for nylon tubing
Does not include a handle and a knob

Product Description

In-Column Mount Trailer Brake Control

Application Summary

Holding

Features & Benefits

A highly reliable in-column mount trailer brake control valve
Made of Engineering Grade Composite (EGC) that is proven tough, light, and corrosion resistant
For this valve, handle applies 50° maximum
Comes with push-to-connect (PTC) fittings for nylon tubing
Does not include a handle and a knob

Haldex Hand Operated Valve

Product Attributes

Delivery Port Diameter	1/4 in.
Exhaust Port Diameter	1/4 in.
Freight Class	70
Supply Port Diameter	1/4 in.

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	8481200070
Harmonized Tariff Code (HTS)	8481200070
Remanufactured Part	N
Warranty Distance	100000
Warranty Distance UOM	MI
Warranty Special	36 MO, 350,000 MI=Haldex Air Brake Valves(1), Automatic Drain Valves (410-10XXX Series)(1). 12 MO, 100,000 MI= Automatic Drain Valves (N20878/ N20879 Series), Height Control Valve, Scale-O-Matic and AC Boxes. See L20221W.pdf for warranty details
Warranty Time	12
Warranty Time UOM	MO
UPC	00767653010014
VMRS Code	013010014

Part Interchanges

HALDEX KN20541 Cross Reference

We have 7 alternatives for the KN20541 by HALDEX:

Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
