Name: Haldex KN20061 Flipper Valve
SKU: kn20061
Price: 75.49 USD
Availability: InStock

HALDEX part description

HALDEX HAND CONTROL VALVE

Hand Operated Push Style Valve for Construction Equipment

Panel mount
Must be manually held in - "Dead Man" type
Made of (EGC) Engineering Grade Composite
Approximate Weight 0.5 lbs.

Notes:

N14514 Plain Knob and N14515AB Push for Emergency Release Faceplate included
Not for use on truck-tractor-trailer application

Technical Specifications:

All Ports:	1/8" in.
Application:	Used on construction equipment
Notes:	Must be manually held in - exhausts when released
OEM Part Number:	N15760G
Approximate Weight:	0.5 lbs.

Haldex Hand Operated Valve

The Haldex hand operated valve enables the user to manually reduce incoming pressure to the desired output pressure. Manufactured by a brand with over 100 years of engineering expertise, this hand control valve delivers superior performance, reliability, and efficiency.

Features & Benefits

A highly reliable push style valve for construction equipment
Comes in panel mount design, making it easy to install
Made of Engineering Grade Composite (EGC) that is proven tough, light, and corrosion resistant
Product must be manually held in "Dead Man" type
Comes with a plain knob and a push for emergency release faceplate
Cannot be used on trucks, tractors, and trailer applications

Product Description

Hand Operated Push Style Valve for Construction Equipment

Application Summary

Used on construction equipment

Features & Benefits

A highly reliable push style valve for construction equipment
Comes in panel mount design, making it easy to install
Made of Engineering Grade Composite (EGC) that is proven tough, light, and corrosion resistant
Product must be manually held in "Dead Man" type
Comes with a plain knob and a push for emergency release faceplate
Cannot be used on trucks, tractors, and trailer applications

Haldex Hand Operated Valve

Product Attributes

Freight Class	70
Port Diameter	1/8 in.

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	8481200070
Harmonized Tariff Code (HTS)	8481200070
Remanufactured Part	N
Warranty Distance	100000
Warranty Distance UOM	MI
Warranty Special	36 MO, 350,000 MI=Haldex Air Brake Valves(1), Automatic Drain Valves (410-10XXX Series)(1). 12 MO, 100,000 MI= Automatic Drain Valves (N20878/ N20879 Series), Height Control Valve, Scale-O-Matic and AC Boxes. See L20221W.pdf for warranty details
Warranty Time	12
Warranty Time UOM	MO
UPC	00767653009964
VMRS Code	013010050

Part Interchanges

HALDEX KN20061 Cross Reference

We have 10 alternatives for the KN20061 by HALDEX:

Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
