Haldex EL16160 - Compressor EL1600
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
HALDEX part description
- Flange Mount, Gear Drive
- Top/Flange Discharge Type
- End Cap Oil Feed
- Flange Oil Drain
- Water Cooled
- Overall Height: 12.19 in.
- Overall Width: 7.10 in.
- Overall Length: 10.11 in.
- External Shaft Length: .61 in.
- Approximate Weight: 48 lbs.
- Service units are furnished without governors and manifolds and may require head rotation and end cap rotation before installation or changeover.
- Torque Nut to 80-100 ft. lbs.
Product Attributes
| Product name | EL1600 DDC Compressor |
| Item Status | Active |
| customer specific | No |
| Related Part | RN26GY RNT26 RNT26A SN144M |
| Product line | Premium line |
| Application | DDC 45° Engines |
| Notes | High Capacity |
| Stroke | 1.50 in. (EL1300) and 1.87 in. (EL1600) |
| Approximate Weight | 48 lbs. |
| Overall Length | 10.11 in. |
| Overall Height | 12.00 in. (EL1300), 12.19 in. (EL1600) |
| (1) OEM Part Number | N7216 Exact Replacement |
| (1) Head Rotation | Right |
| Overall Width | 7.10 in. |
| External Shaft Length | .61 in. |
| Bore Diameter | 2.75 in. |
| Rated Displacement | 13.0 (EL1300) and 16.1 (EL1600) CFM @ 1250 RPM |
| (1) Block Rotation | Right |
Related Parts: 102368CJ E172000 E172001 E172002 E172003 E172004 E172006 EQ2604 EQ2606 EQ2614
Product Description
COMP 1600 DETROIT DIESEL 45
Application Summary
DDC 45° Engines, high capacity
Features & Benefits
- Torque Nut to 80-100 ft. lbs. Includes Installation Gaskets.
Compressor EL1600
Product Attributes
| Cooling Type | Water |
| Bore Diameter | 2.75 IN |
| Discharge Type | Top/Flange |
| Head Rotation | Right |
| Height | 12 in |
| Width | 7.1 in |
| Length | 10.11 in |
| External Shaft Length | 0.61 IN |
| Stroke | 1.50 IN |
| Rated Displacement | 13.0 (EL1300) and 16.1 (EL1600) CFM @ 1250 RPM |
| Block Rotation | Right |
| Related Part | RN26GY, RNT26, RNT26A, SN144M |
| OEM Number | N7216 |
| Prop 65 Short Warning | Cancer & reproductive |
Additional Information
| Remanufactured Part | N |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8414802055 |
| Harmonized Tariff Code (Schedule B) | 8414802055 |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | 36 MO, 350,000 MI=Air Governors(1). 24 MO, 200,000 MI=Air Compressors EL850(4), EL1300(5)(12), EL1600(5)(12), TYPE 292(1), TYPE 365(1). |
| Warranty Special UOM | TX |
Part Interchanges
