Euclid E-9263 - CAMSHAFT, LEFT HAND
$7799
MSRP: $125.98
Save: $47.99
In stock
limited availability at this price!
. Learn more
EUCLID part description
| Application Information 1 | WARNING: These camshafts are for use with fabricated brakes shoes only! DO NOT use these new camshafts with cast brake shoe or fabricated closed roller-end brake shoes. |
| Application Information 1 | WARNING: These camshafts are for use with fabricated brakes shoes only! DO NOT use these new camshafts with cast brake shoe or fabricated closed roller-end brake shoes. |
| Application Information 2 | WARNING: E-586, 1-1/2 in. Diameters, Brake Shoe Rollers must be used with this new head design. E-586 rollers are now available in Brake Repair Kits E-9281, E-9282 and E-9283. |
| Application Information 2 | WARNING: E-586, 1-1/2 in. Diameters, Brake Shoe Rollers must be used with this new head design. E-586 rollers are now available in Brake Repair Kits E-9281, E-9282 and E-9283. |
| Application Information 3 | WARNING: These camshafts should not be used in conjunction with old Fast-Rise camshafts on the same axle. The rate of brake application is different between the two head designs. |
| Application Information 3 | WARNING: These camshafts should not be used in conjunction with old Fast-Rise camshafts on the same axle. The rate of brake application is different between the two head designs. |
| Axle | Trailer |
| Brake Diameter | 12.25 in. |
| Brake Hardware Kit | E10757 (With 1.00 in. O.D. Anchor Pin, E10756 (With 1.25 in. O.D. Anchor Pin) |
| Brake Type | Dana-Spicer |
| Bushing Journal Length | 2.22 in. |
| Camshaft Repair Kit | E2469 (Nylon Bushing); E5307 Bronze Spider Bushing |
| Camshaft Spline Count | 10 |
| Camshaft Spline Diameter | 1.50 in. |
| Effective Length | 16.13 in. |
| Head Type | 5 |
| Left or Right | LH |
| Mfg. Part | Dana-Spicer M12WKL10-163 |
| Notes | 0794L/R Head Fast-Rise. Euclid fabricated open roller end brake shoe numbers are: E-2393A, E-2394A, and E-5303A |
| OE Mfg. | Dana-Spicer |
| Paired Camshaft | E9264 |
| VMRS Code | 013-017-004 |
Product Description
CAMSHAFT-LH
Product Attributes
| Application Information 1 | WARNING: These camshafts are for use with fabricated brakes shoes only! DO NOT use these new camshafts with cast brake shoe or fabricated closed roller-end brake shoes. |
| Application Information 2 | WARNING: E-586, 1-1/2 in. Diameters, Brake Shoe Rollers must be used with this new head design. E-586 rollers are now available in Brake Repair Kits E-9281, E-9282 and E-9283. |
| Application Information 3 | WARNING: These camshafts should not be used in conjunction with old Fast-Rise camshafts on the same axle. The rate of brake application is different between the two head designs. |
| Axle | Trailer |
| Brake Diameter | 12.25 in. |
| Brake Hardware Kit | E10757 (With 1.00 in. O.D. Anchor Pin, E10756 (With 1.25 in. O.D. Anchor Pin) |
| Brake Type | Dana-Spicer |
| Brand | Euclid |
| Bushing Journal Length | 2.22 in. |
| Camshaft Repair Kit | E2469 (Nylon Bushing); E5307 Bronze Spider Bushing |
| Camshaft Spline Count | 10 |
| Camshaft Spline Diameter | 1.50 in. |
| Effective Length | 16.13 in. |
| Head Type | 05 |
| Left Or Right | LH |
| Mfg. Part | Dana-Spicer M12WKL10-163 |
| Notes | 0794L/R Head Fast-Rise. Euclid fabricated open roller end brake shoe numbers are: E-2393A, E-2394A, and E-5303A |
| Oe Mfg. | Dana-Spicer |
| Paired Camshaft | E9264 |
| Pallet Quantity | 180 |
| Weight | 9.03 |
Euclid® is a world leader in the production of precision-engineered replacement parts for buses, trailers, as well as light-, medium- and heavy-duty trucks. This brand takes great pride in its products that meet and even exceed O.E.M. quality standards. Officially a part of Meritor since January 1999, Euclid remains the same despite all the changes the company has been through. When customers receive Euclid products, they know they are getting far more than ordinary replacement parts. Instead, they are getting the best replacement parts made today from a company they can trust. Euclid is a company that's continuously improving with technology to do a job the right way because it is the only way it knows how.
