Haldex DA34105 - Purest Air Dryer
$33649
MSRP: $763.24
Save: $426.75
In stock
limited availability at this price!
. Learn more
HALDEX part description
HALDEX PURest™ AIR DRYER
PURest™ Air Dryer- Multi-Treatment Cartridge employs 5 stages of cleaning to ensure dry system air
- Universal mounting bracket eases retro-fit installations. Fits Pure Air Plus, DRYest, AD type and SS type air dryer bolt patterns
- Integrated turbo protection
- Built-in heater prevents freezing and damage to the dryer
- Fits in 17-3/4" x 9-3/4" x 9-1/2" Envelope. This includes 1/2" clearance needed for desiccant cartridge change
- DA34100 Shown
Technical Specifications:
| Heater: | None |
| Notes: | with Bracket, Inlet Port - Left |
| OEM Part Number: | N4253AD |
| Stages of Drying: | 5 |
| Internal Purge Volume: | 210 cu. in. |
| Inlet Air Temperature: | -40°F to +175°F |
| Maximum Working Pressure: | 150 psi |
| Safety Relief Pressure: | 175 psi |
| Secondary Pressure Protection: | 235 psi |
| 12, 24 Volt Heater: | 95W |
| Flow Capacity: | 34 SCFM |
| Desiccant Cartridge: | 3.5 lbs. |
| Assembly Weight: | 22.0 lbs. |
| Integrated Turbo Protection Pressure Drop: | 2 psi @ 15 SCFM/120 psi |
Haldex PURest Air Dryer
The Haldex PURest air dryer effectively traps oil vapor, water vapor, and other contaminants before they get into and wreak havoc in the air tanks and valves. This component is commonly installed between the air compressor and the "wet tank" of motor coaches and commercial trucks.
Features & Benefits
- Multi-treatment cartridge with five cleaning stages to deliver dry system air
- Ideal for DRYest, Pure Air Plus, AD type, and SS type air dryer bolt patterns
- Comes with universal mounting bracket for hassle-free installation
- With integrated heater that helps prevent freeze-up on winter and damage to the dryer
- Provided with built-in turbo protection
Product Description
PURest™ Air Dryer
Features & Benefits
- Multi-treatment cartridge with five cleaning stages to deliver dry system air
- Ideal for DRYest, Pure Air Plus, AD type, and SS type air dryer bolt patterns
- Comes with universal mounting bracket for hassle-free installation
- With integrated heater that helps prevent freeze-up on winter and damage to the dryer
- Provided with built-in turbo protection
Haldex PURest Air Dryer
The Haldex PURest air dryer effectively traps oil vapor, water vapor, and other contaminants before they get into and wreak havoc in the air tanks and valves. This component is commonly installed between the air compressor and the "wet tank" of motor coaches and commercial trucks.
Product Attributes
| Airflow Rate | 34 SCFM |
| Dessicant Cartridge Weight | 3.5 lbs. |
| Drying Stages | 5 |
| Freight Class | 70 |
| Heater Included | No |
| Integrated Turbo Protection Pressure Drop | 2 PSI @ 15 SCFM/120 PSI |
| Internal Purge Volume | 210 cu. in. |
| Maximum Working Pressure | 150 PSI |
| Maximum Working Temperature | 175°F |
| Minimum Working Temperature | -40°F |
| Mounting Bracket Included | Yes |
| New Or Remanufactured | New |
| Notes | With Inlet Port at Left Side |
| Safety Relief Pressure | 175 PSI |
| Secondary Pressure Protection | 235 PSI |
| Series | PURest™ |
| Wattage | 95 Watts |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8421398015 |
| Harmonized Tariff Code (HTS) | 8421398015 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | See Haldex Aftermarket Product warranty Policy (L20221W).pdf |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653283166 |
| VMRS Code | 013010252 |
Part Interchanges
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
