Haldex BE22090 - Junction Box
$2799
MSRP: $55.26
Save: $27.27
In stock
limited availability at this price!
. Learn more
HALDEX part description
HALDEX JUNCTION BOX
6-Terminal Style Junction Box- Integrally molded terminal bar.
- Available in flush mount or 1/4-20 stud mount (3/4" length).
- 10-32 terminals (6).
- 2" overall height with 3" mounting centers.
- 1/4" knockouts for flush mounting.
Notes:
- Use BE20510 for Replacement Cover.
Technical Specifications:
| Style: | T |
| Mounting Style: | Flush |
| Grommet Positions: | A, B, C, D |
| Remarks: | Openings per Drawing |
| OEM Number: | 20709 |
Haldex Midland Junction Box
The Haldex Midland junction is a high-quality replacement to your old or worn junction box. Manufactured by a brand with over 100 years of experience, this genuine 7-terminal style junction box is built using high-quality materials to help maintain the top condition of your electrical system.
Features & Benefits
- Designed with integrally molded terminal bar
- Comes available in flush mount or 1/4-20 stud mount (3/4" length)
- With precision-molded Engineering Grade Composite (EGC) construction
- Uses optional circuit breaker or terminal design 10-32 terminals
- Product has an overall height of 2.5” with 3” mounting centers
- With 1/4" knockouts for flush mounting
Product Description
6-Terminal Style Junction Box
Application Summary
6-Terminal Style Junction Box
Features & Benefits
- Designed with integrally molded terminal bar
- Comes available in flush mount or 1/4-20 stud mount (3/4" length)
- With precision-molded Engineering Grade Composite (EGC) construction
- Uses optional circuit breaker or terminal design 10-32 terminals
- Product has an overall height of 2.5” with 3” mounting centers
- With 1/4" knockouts for flush mounting
Haldex Midland Junction Box
The Haldex Midland junction is a high-quality replacement to your old or worn junction box. Manufactured by a brand with over 100 years of experience, this genuine 7-terminal style junction box is built using high-quality materials to help maintain the top condition of your electrical system.
Product Attributes
| Anchor Bracket Style | T (Terminal) |
| Freight Class | 70 |
| Grommet Positions | A, B, C, D |
| Mounting Type | Flush |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8536908530 |
| Harmonized Tariff Code (HTS) | 8536908530 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | 24 MO, 200,000 MI=All Other Tour Bus, Intercity Transit Products Not Listed(8). 12MO,100,000 MI= All Other New Products Not Listed(13), City Transit Oper.(9) (All New Products), Friction Products(7), New Clutches(6). See L20221W.pdf for warranty details |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653086057 |
| VMRS Code | 034004031 |
Part Interchanges
HALDEX BE22090 Cross Reference
We have 5 alternatives for the BE22090 by HALDEX:
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
