Name: Haldex 90554930 Air Susp. Linkage
SKU: 90554930
Price: 21.99 USD
Availability: InStock

HALDEX part description

HALDEX HEIGHT CONTROL VALVE LINKAGE

Adjustable Linkage Kit

Technical Specifications:

Length:	15.5"
Notes:	OEM "Only"
Kit Contents:	Adjustable Linkage Link End Pin Link Hose Clamp Washers Hex Nuts

Haldex Adjustable Linkage Kit

The Haldex adjustable linkage kit contains the necessary components to replace the linkage for the Haldex air suspension sensor. It is designed for easy installation and can be adjusted to various lengths.

Features & Benefits

With a universal-fit design similar to those used by OE manufacturers
Can be adjusted up to 19 inches to accommodate various systems
Linkage can be cut according to the desired length
Designed the linkage with a fixed looped end for maximum durability
Easy to install and comes included with necessary hardware

Product Description

Adjustable Loop Linkage 15.5"

Features & Benefits

Made using proven materials and state-of-the-art technology
Designed to strict OE specifications to work and fit seamlessly
Meticulously engineered to ensure reliable performance
A common truck/tractor suspension linkage that's used by several OE manufacturers

Haldex Adjustable Linkage

For your height control valve's efficient performance, make sure to use only the high-quality Haldex adjustable linkage. Together with the height control valve, this product helps maintain the truck's ride height as loads increase and decrease.

Product Attributes

Freight Class	70
Kit Content	Adjustable Linkage, Link End, Pin Link, Hose Clamp, Washers, and Hex Nuts
Linkage Arm Length	15.5 in.

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	8481909040
Harmonized Tariff Code (HTS)	8481909040
Remanufactured Part	N
Warranty Distance	100000
Warranty Distance UOM	MI
Warranty Special	24 MO, 200,000 MI=Air Compressors EL850(4), EL1300(5), EL1600(5), Tu-Flo 501/550(4), Tu-Flo 700/750(4), 12 MO, 100,000 MI=All Other REMAN Products Not Listed(13). See L20221W.pdf for warranty details
Warranty Time	12
Warranty Time UOM	MO
UPC	00767653268217
VMRS Code	016008024

Part Interchanges

HALDEX 90554930 Cross Reference

We have 2 alternatives for the 90554930 by HALDEX:

Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
