Gates 32048 - HEXHEAD CLAMP, SUPER
- Part Number
- 32048
- Manufacturer
- GATES CORPORATION
- Description
-
HEXHEAD CLAMP, SUPER
details
$189
MSRP: $7.95
Save: $6.06
In stock
limited availability at this price!
. Learn more
GATES CORPORATION part description
Technical Specifications
| Weight Lbs | .09 |
| Category Name Description | Top quality clamps with extra-strength construction features. Super Hex clamps feature a 1/2" wide band, while the Minex band is 5/16". |
| Features Advantages | One-piece screw housing is interlocked onto band for extra strength. Solid head forged from one piece of steel, cadmium plated. Hex shaped screw with deep slot - tightens with screwdriver, nutdriver or socket wrench. Tighten to 30 in./lbs. Meets SAE J1508. Durable 200 series stainless steel band and screw housing. |
| Type | Stainless Steel (Standard) |
| Screw Type | Deep Slot Hex-Head |
| Band Width in | .5 |
| Clamping Range Max in | 3.5 |
| Clamping Range Min in | 1.625 |
| Maximum Torque inlbs | 50 |
| Recommended Torque inlbs | 25-35 |
| Hose ID Max in | 3 |
| Hose ID Min in | 2.5 |
| Size | 48 |
Product Description
Stainless Steel Hose Clamp
Features & Benefits
- Durable 200 series stainless steel band and screw housing
- One-piece screw housing is interlocked onto band for extra strength
- Cadmium-plated solid head forged from one piece of steel
- Hex-shaped screw has a deep slot that tightens with a screwdriver, nut driver or socket wrench
- NOTE: Tighten Minex clamps to minimum 14-16 in. lb. (maximum of 20 in. lb.)
- NOTE: Super Hex clamps to minimum 25-35 in. lb. (maximum of 50 in. lb.)
Product Attributes
| Material | Stainless Steel |
| Adjustment Type | Stainless Steel (Standard) |
| Band Width | .5 IN |
| Maximum Torque | 50 |
| Housing Material | Stainless Steel |
| 3872 | 3.5 IN |
| 3873 | 1.625 IN |
| 4172 | 2.5 IN |
| 4438 | 3 IN |
| 9816 | 25-35 |
| 9817 | Deep Slot Hex-Head |
| 9867 | 48 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| UPC | 00072053021721 |
| VMRS Code | 053008020 |
| UNSPSC | 31162900 |
Part Interchanges
- Interstate 2048
- Norton Body Supply 013-48
- Stant SC48
- Velvac 022348
- ACDelco 32048C
- Dayco 91048
- Dayco KH48
- Carquest 1048
- Robertshaw 2048
- Aero-Seal M48S
- Goodyear 51048
- Ideal Tridon 5748190
- Ideal Tridon 670040048
- Ideal Tridon 670040048051
- Hy-Gear 5048
- Hy-Gear 5248
- Hy-Gear 5448
- Hy-Gear 6448
- Murray Gold Seal GS 50
- NAPA 705-1023
- NAPA 705-1082
- NAPA 705-1142
- Sure-Tite 48
- Sure-Tite 48H
- Sure-Tite C48P
GATES CORPORATION 32048 Cross Reference
We have 2 alternatives for the 32048 by GATES CORPORATION:
The Gates Corporation® helps keep the industry running by providing top-of-the-line solutions that minimize downtime and lost production. From trucking and automotive to mining and specialty manufacturing, Gates provides best-in-class belts and power transmission solutions that maximize the production and capabilities of top companies, making them outshine the competition. Gates Corporation had its beginnings in 1911, when Charles C. Gates purchased a tire and rubber company and established a shop in Denver, Colorado. More than 100 years later, the small, family-owned company has grown into a global leader, employing over 15,000 people in its 100 facilities in 30 countries. Gates Corporation’s product portfolio includes power transmission parts, fluid power solutions, and many other products for various applications including automotive, construction, bicycles, consumer equipment, heavy-duty industrial equipment, food and beverage, and HVAC equipment.
