WIX FILTERS part description

Product Specifications

Part Number:	24723
UPC Number:	765809247239
Style:	Spin-On Fuel/Water Separator Filter
Service:	Fuel
Type:	Full Flow
Media:	Microglass
Height:	9.118 (232)*
Outer Diameter Top:	4.537 (115)*
Outer Diameter Bottom:	3.735 (95)*
Inside Diameter Top:	1.17 (30)*
Inside Diameter Bottom:	Closed:
Thread Size:	15X4 MM
Max Flow Rate:	1
Nominal Micron Rating:	5
Operating Temp. (min):	-40
Operating Temp. (max):	219

( )* denotes metric

Gasket Diameters

Number	O.D.	I.D.	Thk.
Packed	4.188 (106)*	3.906 (99)*	0.141 (4)*

Principle Application:

Dodge Ram Pickup w/ 6.7L Cummins Diesel (07-09), Sterling Trucks - this is the complete assembly w/ drain + sensor - includes the replacement cartridge # 33733 that goes in the assembly - install the complete assembly the first time, then only the element 33733 is required

Product Description

WIX Spin-On Fuel/Water Separator Filter

Application Summary

This is the complete assembly w/ drain + sensor - includes the replacement cartridge # 33733 that goes in the assembly - use this part the first time, then only use the replaceable element # 33733 is required.

Product Attributes

Class	HC
Collapsed Pressure Rating	50 PSI
Drain Cock	1
Duty Type	HD
Flow Rate	1 GPM
Height	9.118 in
Maximum Operating Temperature	219 F
Media Material	Microglass
Micron	5.00 Micron
Minimum Operating Temperature	-40 F
Outer Diameter Bottom	3.735 in
Outer Diameter Top	4.537 in
Style	Spin-On Fuel/Water Separator F
Thread Size	15X4 MM IN

Additional Information

Country of Origin (Primary)	US
Harmonized Tariff Code (HTS)	8421230000
Remanufactured Part	N
UPC	00765809247239

Part Interchanges

WIX FILTERS 24723 Cross Reference

We have 2 alternatives for the 24723 by WIX FILTERS:

Since its establishment in 1939, the name WIX Filters® has been synonymous with a strong tradition of excellence. This brand opened its door to business in an old cotton mill in Gastonia to provide its customers with premium-quality filters that exceed their performance demands. Within 15 years since it was founded, WIX Filters have revolutionized the automotive filtration system by introducing and patenting the spin-on oil filter design called “twist of the wrist,” which quickly became the industry standard. The eight decades of growth and innovation made WIX Filters a global leader in filtration, with over 12,000 unique product numbers covering a wide range of fuel, oil, air, coolant, cabin air, and transmission filters for domestic and foreign vehicles and industrial applications and more than 8,000 part numbers for fluid power systems and hydraulic applications.
