WIX FILTERS part description

Product Specifications

Part Number:	51612
UPC Number:	765809516120
Style:	Spin-On Power Steering Filter
Service:	Power Steering
Type:	Full Flow
Media:	Enhanced Cellulose
Height:	4.338 (110)*
Outer Diameter Top:	3.66 (93)*
Outer Diameter Bottom:	Closed:
Thread Size:	13/16-16
By-Pass Valve Setting-PSI:	7-9
Beta Ratio:	2/20=6/20
Nominal Micron Rating:	21

( )* denotes metric

Gasket Diameters

Number	O.D.	I.D.	Thk.
Attached	2.834 (72)*	2.462 (63)*	0.200 (5)*

Principle Application:

Power Steering on IHC Trucks

Product Description

WIX Spin-On Power Steering Filter

Application Summary

Power Steering on IHC Trucks

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Product Attributes

BetaRatio	2/20=6/20
Bypass Relief Valve Setting	7-9
Class	HW
Duty Type	HD
Height	4.338 in
Inner Diameter Top	Closed
Media Material	Enhanced Cellulose
Micron	21.00 Micron
Outer Diameter Top	3.660 in
Style	Spin-On Power Steering Filter
Thread Size	13/16-16 IN

Additional Information

Country of Origin (Primary)	US
Harmonized Tariff Code (HTS)	8421230000
Remanufactured Part	N
UPC	00765809516120

Part Interchanges

Since its establishment in 1939, the name WIX Filters® has been synonymous with a strong tradition of excellence. This brand opened its door to business in an old cotton mill in Gastonia to provide its customers with premium-quality filters that exceed their performance demands. Within 15 years since it was founded, WIX Filters have revolutionized the automotive filtration system by introducing and patenting the spin-on oil filter design called “twist of the wrist,” which quickly became the industry standard. The eight decades of growth and innovation made WIX Filters a global leader in filtration, with over 12,000 unique product numbers covering a wide range of fuel, oil, air, coolant, cabin air, and transmission filters for domestic and foreign vehicles and industrial applications and more than 8,000 part numbers for fluid power systems and hydraulic applications.
