Name: Hayden 401 Trans Oil Cooler
SKU: 401
Price: 27.99 USD
Availability: InStock

HAYDEN part description

Features:

Size is 3/4 inch x 5 inch x 12-1/2 inch
Sub-compact to compact cars
GVWR up to 12,000 pounds
Ultrasonically soldered for durability
100 percentage pressure tested

Product Description

Ultra-Cool Transmission Oil Cooler

Application Summary

Acura Vehicles (15-86) >> AMC Cars (88-58) >> Buick Vehicles (15-75) >> Cadillac Vehicles (15-82) >> Chevy Cars (15-61); Trucks (15-63); Vans (14-63) >> Chrysler Vehicles (14-78) >> Dodge Cars (15-42); Mini Vans (14-84); Trucks (14-42); Van

Product Attributes

Description	--- - Transmission Oil Cooler
Mounting Hardware Included?	--- - Included
Inlet Fitting Fraction	3/8"
Length IN	--- - '12.500'
Length MM	--- - '317.500'
Height IN	--- - '5.000'
Height MM	--- - '127.000'
Depth IN	--- - '0.750'
Depth MM	--- - '19.050'
Package Height IN	--- - '13.500'
Package Height MM	--- - '342.900'
Package Length IN	--- - '11.500'
Package Length MM	--- - '292.100'
Package Depth IN	--- - '1.750'
Package Depth MM	--- - '44.450'
Original Equipment Replacement?	--- - 'Yes'
Performance Rated?	--- - 'Yes'
Printed Foot Note	--- - Size - 5" x 12 1/2"
Overall Height IN	--- - '13.500'
Overall Height MM	--- - '342.900'
Overall Width IN	--- - '1.750'
Overall Width MM	--- - '44.450'
Type	--- - Ultra-Cool
Hose Size Number	3/8"
Bracket?	--- - w/o Bracket
Inlet Fitting IN	0.375
Inlet Fitting MM	9.525
Material	--- - Aluminum
Outlet Fitting Size IN	0.375
Outlet Fitting Size MM	9.525
Color	--- - Silver
Gasket / Seals Included?	--- - Not Included
Hose Working Pressure	200
Hose Minimum Burst Pressure	300
Row Quantity	4
Equiped with Electric Fan?	No
Core Tube Dia. IN	0.500
Core Tube Dia. MM	12.700
Core Tube I.D. IN	0.438
Core Tube I.D. MM	11.113
Contains Spring?	No
Fittings Included?	Fittings Not Included
Hose I.D. IN	0.344
Hose I.D. MM	8.731
Hose Length IN	54
Hose Length MM	1371.600
