Haldex EL16280X - Compressor 1600
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
HALDEX part description
Specifications:
| Series/Model: | EL1600 |
| Mounting Type: | 3-Hole Flange Mount |
| Block Rotation Direction: | Right |
| Bore Diameter: | 2.75 in. |
| Cooling Type: | Water |
| External Shaft Length: | 1.85 in. |
| Head Rotation: | Right |
| Height: | 12.19 in. |
| Length: | 11.31 in. |
| OEM Number: | NT7228A |
| Operation: | Gear Driven |
| Rated Displacement: | 16.1 CFM at 1250 RPM |
| Related Part: | RN26HA, RNT26, RNT26A, SN144F |
| Stroke Length: | 1.87 in. |
| Width: | 5.44 in. |
| Freight Class: | 60 |
| UPC (GTIN): | 767653331423 |
| VMRS Code: | 013009001 |
| Harmonized Tariff Code: | 8414802055 |
Haldex EL1600 Caterpillar Compressor
The Haldex EL1600 Caterpillar compressor is designed to effectively pump compressed air into the air reservoirs before it is used by your truck’s air brake system. A part of Haldex’s comprehensive range of new air brake compressors, this product is manufactured to meet the highest standards to ensure quality, performance, and reliability.
Features & Benefits
- Built to offer a quick, trouble-free installation
- Designed to last longer than the competing units
- Product’s port orientation is viewed from the front
- Stringently evaluated to guarantee proper fit and function
Product Description
Remanufactured Compressor Cat 1600
Application Summary
Caterpillar 3116 Engine
Features & Benefits
- Built to offer a quick, trouble-free installation
- Designed to last longer than the competing units
- Product’s port orientation is viewed from the front
- Stringently evaluated to guarantee proper fit and function
Haldex EL1600 Caterpillar Compressor
The Haldex EL1600 Caterpillar compressor is designed to effectively pump compressed air into the air reservoirs before it is used by your truck’s air brake system. A part of Haldex’s comprehensive range of new air brake compressors, this product is manufactured to meet the highest standards to ensure quality, performance, and reliability.
Product Attributes
| Block Rotation | Right |
| Bore Diameter | 2-3/4 in. |
| Cooling Type | Water |
| External Shaft Length | 1.85 in. |
| Freight Class | 60 |
| Head Rotation | Right |
| Height | 12.19 in. |
| Length | 11.31 in. |
| Mounting Type | 3-Hole Flange Mount |
| New Or Remanufactured | Remanufactured |
| Operation | Gear Driven |
| Rated Displacement | 16.1 CFM @ 1250 RPM |
| Series | EL1600 |
| Stroke Length | 1.87 in. |
| Width | 5.44 in. |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8414802055 |
| Harmonized Tariff Code (HTS) | 8414802055 |
| Remanufactured Part | Y |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | 24 MO, 200,000 MI=Air Compressors EL850(4), EL1300(5), EL1600(5), Tu-Flo 501/550(4), Tu-Flo 700/750(4), 12 MO, 100,000 MI=All Other REMAN Products Not Listed(13). See L20221W.pdf for warranty details |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653331423 |
| VMRS Code | 013009001 |
Part Interchanges
- EL16280
- 065601
- 106-7851
- 8HE32
- Midland EL16280
- BENDIX 065601
- Caterpillar 106-7851
- Oshkosh 8HE32
- MIDLAND EL16280
- MIDLAND EL16280X
- Bendix 108327
- Bendix 108329
- Bendix 109551
- BENDIX 109552
- Bendix 5000799
- Caterpillar 106-7852
- Caterpillar 109626
- Caterpillar 122-1713
- BENDIX 108327
- BENDIX 108329
- BENDIX 109551
- BENDIX 5000799
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
