Name: Velvac 699297 Speaker Style Back-up Alarm, 97 Decibel, Terminal Connection
SKU: 699297
Price: 24.49 USD
Availability: InStock

VELVAC part description

Item Overview:

Each of Velvac's new backup alarms is encapsulated in epoxy, to protect the alarm from the job site environment, and allowing for steam cleaning and pressure washing.
The reduced epoxy design provides the durability needed in a back-up alarm, while the thinner coat of epoxy aids in the dissipation of heat, keeping the alarm cooler and extending its life.
A reverse polarity system protects each alarm in the event of lead reversal.
Alarm housings are made of high impact, glass filled nylon to meet the high temperature requirements of SAE J994 and also UL requirements for flame tests, while providing the durability needed in harsh environments.
Each speaker style back-up alarm features the 3.25≈ industry standard bolt mounting pattern, and either bottom or side mounting. This mounting pattern, along with the compact design, allows for easy replacement and installation, even in the tightest of spaces.
Manufactured with a Polyethylenimine (PEI) speaker cone, the speaker style alarms are designed to meet the rigorous SAE temperature requirements of -40 to +85 degrees Celsius.
Since the number one failure point in speakers is the speaker wires, Velvac's alarms use multi-stranded wire for longer speaker life.

Specifications:

Style	Speaker
Voltage	12 - 24 Volts
Connection Type	Terminal
Decibels	97
Preco	230 / 240
Eco	510 / 520

Velvac Speaker Style Back-up Alarm

Designed to efficiently alert vehicles or pedestrians that your truck or vehicle is moving in reverse, the Velvac back-up alarm might be the final piece you need to fully restore your rig’s safety and road worthiness. Its compact and durable construction makes it capable of working well even in the harshest of environments.

Features & Benefits

Each back-up alarm comes with polarity reverse system for lead reversal protection
Meets SAE J994 high temperature requirements and UL requirements for flame testing
Comes with a polyetherimide (PEI) speaker cone and multi-stranded wire for longer speaker life
Passed the rigorous SAE temperature requirements of -40 to +85 degrees Celsius
Industry-standard bolt mounting pattern and compact design allows easy installation even in tight spaces
Epoxy- encapsulated for protection against job site environment, steam cleaning and pressure washing

Product Description

Speaker Style Back-up Alarm

Features & Benefits

Each back-up alarm comes with polarity reverse system for lead reversal protection
Meets SAE J994 high temperature requirements and UL requirements for flame testing
Comes with a polyetherimide (PEI) speaker cone and multi-stranded wire for longer speaker life
Passed the rigorous SAE temperature requirements of -40 to +85 degrees Celsius
Industry-standard bolt mounting pattern and compact design allows easy installation even in tight spaces
Epoxy- encapsulated for protection against job site environment, steam cleaning and pressure washing

Product Attributes

Connection Type	Terminal
Decibels	97
Style	Speaker
Voltage	12 - 24 Volts

Part Interchanges

VELVAC 699297 Cross Reference

We have 6 alternatives for the 699297 by VELVAC:

Velvac® is a leading manufacturer of air brake and valve components for heavy duty trucks. Founded in 1934 as Vacuum Power Equipment Company, the company has grown tremendously over the years with new products included in its catalog, such as mirrors, cameras and vision systems, fuel system products, and accessories. Six years after Vacuum Power Equipment Company opened its doors for business, its name was changed to "Velvac" because of the popularity of its Velvet Vacuum Brakes brand. Today, Velvac continues to expand and upgrade its broad product categories to meet its customers' increasing demands. Its main headquarters is in New Berlin, WI, and its primary manufacturing facility is in Reynosa, Mexico.
