Haldex EL16250X - Reman Compressor
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
HALDEX part description
Specifications:
| Series/Model: | EL1600 |
| Mounting Type: | Flange Mount |
| Block Rotation Direction: | Left |
| Bore Diameter: | 2.75 in. |
| Cooling Type: | Water |
| Discharge Type: | Flange - Top |
| External Shaft Length: | 0.19 in. |
| Head Rotation: | Left |
| Height: | 12.17 in. |
| Length: | 10.31 in. |
| OEM Number: | N7225 |
| Operation: | Gear Driven |
| Rated Displacement: | 16.1 CFM at 1250 RPM |
| Related Part: | RN26GY, RNT26, RNT26A, SN144C |
| Stroke Length: | 1.87 in. |
| Width: | 6.94 in. |
| Freight Class: | 60 |
| UPC (GTIN): | 767653026213 |
| VMRS Code: | 013009001 |
| Harmonized Tariff Code: | 8414802055 |
Haldex Like-Nu EL1600 DDC Compressor
The Haldex Like-Nu EL1600 DDC compressor is designed to effectively pump compressed air into the air reservoirs before it is used by your truck’s air brake system. It went through rigorous remanufacturing and testing processes to ensure it performs according to the original manufacturer's specifications.
Features & Benefits
- Includes the necessary gaskets for a quick, trouble-free installation
- Product’s port orientation is viewed from the front
- Stringently evaluated to guarantee proper fit and function
- A cost-effective replacement for your worn or damaged air brake compressor
Product Description
Remanufactured Compressor 1600 Detroit Diesel 75°
Application Summary
DDC 75° Engines , Bus Applications
Features & Benefits
- Includes the necessary gaskets for a quick, trouble-free installation
- Product’s port orientation is viewed from the front
- Stringently evaluated to guarantee proper fit and function
- A cost-effective replacement for your worn or damaged air brake compressor
Haldex Like-Nu EL1600 DDC Compressor
The Haldex Like-Nu EL1600 DDC compressor is designed to effectively pump compressed air into the air reservoirs before it is used by your truck’s air brake system. It went through rigorous remanufacturing and testing processes to ensure it performs according to the original manufacturer's specifications.
Product Attributes
| Block Rotation | Left |
| Bore Diameter | 2-3/4 in. |
| Cooling Type | Water |
| Discharge Type | Flange - Top |
| External Shaft Length | 0.19 in. |
| Freight Class | 60 |
| Head Rotation | Left |
| Height | 12.17 in. |
| Length | 10.31 in. |
| Mounting Type | Flange Mount |
| New Or Remanufactured | Remanufactured |
| Operation | Gear Driven |
| Rated Displacement | 16.1 CFM @ 1250 RPM |
| Series | EL1600 |
| Stroke Length | 1.87 in. |
| Width | 6.94 in. |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8414802055 |
| Harmonized Tariff Code (HTS) | 8414802055 |
| Remanufactured Part | Y |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | 24 MO, 200,000 MI=Air Compressors EL850(4), EL1300(5), EL1600(5), Tu-Flo 501/550(4), Tu-Flo 700/750(4), 12 MO, 100,000 MI=All Other REMAN Products Not Listed(13). See L20221W.pdf for warranty details |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653026213 |
| VMRS Code | 013009001 |
Part Interchanges
- E-BN278445X
- EL16250
- N7225
- 106793
- ZZEL16250
- 23509473
- KN16250N
- EUCLID E-BN278445X
- MIDLAND EL16250
- PRIOR N7225
- Bendix 106793
- NAVISTAR ZZEL16250
- Detroit Diesel 23509473
- NAPA KN16250N
- Euclid E-BN289790X
- EUCLID E-MDEL16250X
- MIDLAND EL16250X
- Midland KN16250
- MIDLAND KN16250N
- Midland KN16250X
- MIDLAND KNT16250
- Midland N7225
- BENDIX 106793
- BENDIX 107494
- Bendix 108622
- BENDIX 275631
- BENDIX 275777
- BENDIX 277560
- Bendix 278445
- BENDIX 278681
- Bendix 279890
- BENDIX 280573
- Bendix 289263
- BENDIX 289790
- BENDIX 289915
- Detroit Diesel R23509473
- EUCLID E-BN289790X
- MIDLAND KN16250
- MIDLAND KN16250X
- MIDLAND N7225
- BENDIX 108622
- BENDIX 278445
- BENDIX 279890
- BENDIX 289263
HALDEX EL16250X Cross Reference
We have 3 alternatives for the EL16250X by HALDEX:
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
