Haldex EL13280X - Reman Compressor
$27999
+$187.50 Core Deposit
Total price w/ core: $467.49
MSRP: $634.89
Save: $354.90
In stock
limited availability at this price!
. Learn more
HALDEX part description
Specifications:
| Series/Model: | EL1300 |
| Mounting Type: | 2-Hole Flange Mount |
| Block Rotation Direction: | Right |
| Bore Diameter: | 2.75 in. |
| Cooling Type: | Water |
| External Shaft Length: | 2.23 in. |
| Head Rotation: | Right |
| Height: | 12.51 in. |
| Length: | 11.8 in. |
| OEM Number: | NT7028C |
| Operation: | Gear Driven |
| Rated Displacement: | 13.0 CFM at 1250 RPM |
| Related Part: | KNT17090X,RN26GX, RNT26, RNT26A |
| Stroke Length: | 1.5 in. |
| Width: | 7.66 in. |
| Freight Class: | 60 |
| UPC (GTIN): | 767653198927 |
| VMRS Code: | 013009001 |
| Harmonized Tariff Code: | 8414802055 |
Haldex Like-Nu EL1300 Caterpillar Compressor
The Haldex Like-Nu EL1300 Caterpillar compressor is designed to effectively pump compressed air into the air reservoirs before it is used by your truck’s air brake system. It went through rigorous remanufacturing and testing processes to ensure it performs according to the original manufacturer's specifications.
Features & Benefits
- Offers a quick, trouble-free installation
- Product’s port orientation is viewed from the front
- Stringently evaluated to guarantee proper fit and function
- A cost-effective replacement for your worn or damaged air brake compressor
Product Description
Remanufactured Compressor 1300 Cat 3126 Nt7028C
Application Summary
Caterpillar #145-2906
Features & Benefits
- Offers a quick, trouble-free installation
- Product’s port orientation is viewed from the front
- Stringently evaluated to guarantee proper fit and function
- A cost-effective replacement for your worn or damaged air brake compressor
Haldex Like-Nu EL1300 Caterpillar Compressor
The Haldex Like-Nu EL1300 Caterpillar compressor is designed to effectively pump compressed air into the air reservoirs before it is used by your truck’s air brake system. It went through rigorous remanufacturing and testing processes to ensure it performs according to the original manufacturer's specifications.
Product Attributes
| Block Rotation | Right |
| Bore Diameter | 2-3/4 in. |
| Cooling Type | Water |
| External Shaft Length | 2.23 in. |
| Freight Class | 60 |
| Head Rotation | Right |
| Height | 12.51 in. |
| Length | 11.8 in. |
| Mounting Type | 2-Hole Flange Mount |
| New Or Remanufactured | Remanufactured |
| Operation | Gear Driven |
| Rated Displacement | 13 CFM @ 1250 RPM |
| Series | EL1300 |
| Stroke Length | 1-1/2 in. |
| Width | 7.66 in. |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8414802055 |
| Harmonized Tariff Code (HTS) | 8414802055 |
| Remanufactured Part | Y |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | 24 MO, 200,000 MI=Air Compressors EL850(4), EL1300(5), EL1600(5), Tu-Flo 501/550(4), Tu-Flo 700/750(4), 12 MO, 100,000 MI=All Other REMAN Products Not Listed(13). See L20221W.pdf for warranty details |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653198927 |
| VMRS Code | 013009001 |
Part Interchanges
HALDEX EL13280X Cross Reference
We have 2 alternatives for the EL13280X by HALDEX:
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
