Centric 130.35003 - Premium Brake Master Cylinder
$35749
MSRP: $516.99
Save: $159.50
In stock
limited availability at this price!
. Learn more
CENTRIC part description
| Make | Mercedes-Benz |
| Model | 230, 240D, 280, 280C, 280CE, 280E, 280S, 280SE, 300D, 450SE, 450SEL, 450SL, 450SLC |
| Year | 1975 |
Product Description
Centric Premium Brake Master Cylinder
Application Summary
Mercedes-Benz 230 1978-1975, 240D 1979-1976, 280 1976-1975, 280C 1976-1975, 280CE 1978, 280E 1978-1977, 280S 1976-1975, 280SE 1977, 300D 1977-1975, 450SE 1976-1975, 450SEL 1977-1975, 450SL 1977-1975, 450SLC 1977-1975
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
Centric; CentricParts; Centric Parts; Centric Master Cylinder; Centric Parts Master Cylinder
Product Attributes
| Reservoir Material | Plastic |
| Mounting Hardware Included | No |
| Gasket Or Seal Included | Yes |
| Mounting Hole Quantity | 2 |
| Brake Booster Included | No |
| Master Cylinder Cap Included | No |
| Master Cylinder Material | Cast Iron |
| Pushrod Included | No |
| Reservoir Included | No |
| Primary Outlet Thread Diameter | 10.000 MM |
| Secondary Outlet Thread Diameter | 10.000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 3 |
| Mounting Bracket Included | No |
| Secondary Outlet Thread Pitch | 1.00 MM |
| Primary Outlet Thread Pitch | 1.00 MM |
| Bore Type | Stepped |
| 9556 | M10-1.00 |
| 9557 | M10-1.00 |
| 9560 | Yes |
| 9561 | 1 |
| 9562 | No |
| 9566 | Bubble |
| 9567 | Bubble |
| 9568 | 23.000 MM |
| 9569 | 19.000 MM |
| 9570 | Removable |
| Boss, Nipple Or Port: Front, Left: #a [cntrc] | M10-1.00 bbl |
| Boss, Nipple Or Port: Front, Left: #b [cntrc] | M12-1.00 bbl |
| Boss, Nipple Or Port: Rear, Right: #a [cntrc] | M10-1.00 bbl |
| Boss, Nipple Or Port: Rear: #a [cntrc] | M10-1.00 bbl |
| Master Cylinder Bore Diameter Secondary [cntrc] In | 0.748 |
| Master Cylinder Bore Diameter Secondary [cntrc] Mm | 19.000 |
| Primary Outlet Flare Type [cntrc] | Bubble |
| Publication Bore [cntrc] | 23mm - 19mm |
| Push Rod: Length / Depth [cntrc] In | 1.92 |
| Secondary Outlet Flare Type [cntrc] | Bubble |
| Weight [cntrc] Kgs | 1.41 |
| Weight [cntrc] Lbs | 3.1 |
Additional Information
| Country of Origin (Primary) | DE |
| Harmonized Tariff Code (HTS) | 8413919050 |
| NAFTA Preference Criterion Code | B |
| UPC | 00805890001348 |
Fits Vehicles
- Mercedes-Benz 450SLC (1975-1977)
- Mercedes-Benz 450SL (1975-1977)
- Mercedes-Benz 450SEL (1975-1977)
- Mercedes-Benz 450SE (1975-1976)
- Mercedes-Benz 300D (1975-1977)
- Mercedes-Benz 280SE (1977)
- Mercedes-Benz 280S (1975-1976)
- Mercedes-Benz 280E (1977-1978)
- Mercedes-Benz 280CE (1978)
- Mercedes-Benz 280C (1975-1976)
- Mercedes-Benz 240D (1976-1979)
- Mercedes-Benz 280 (1975-1976)
- Mercedes-Benz 230 (1975-1978)
