Name: Haldex AL919342 Ecuplcs2M A7 Din
SKU: al919342
Price: 392.99 USD
Availability: InStock

HALDEX part description

Width:	8 in.
Voltage:	12
Related Part:	A027533909, A027534009, L30041
Recommended Use:	supports all 4S/2M (or 2S/2M) applications
OEM Part Number:	202028AB
Height:	4.25 in.
ECU Specifications:	SLH-A7
Freight Class:	70
VMRS Code:	013011076
UPC (GTIN):	767653333328
Harmonized Tariff Code:	8543709960

Haldex ABS Electronic Control Unit

Equip your truck’s anti-lock braking system with a high-quality Haldex ABS electronic control unit for improved traction. This product offers improved reliability to avoid unexpected breakdown and costly downtime.

Features & Benefits

No intermediate cables required when connecting the wheel speed sensor and trailer power to the ECU
Single fastener design guarantees quick and easier serviceability and reduced maintenance costs
With potted ECU enclosure to withstand impacts, electrical overload, and extreme temperatures
PLC Select 2M ECU that supports all 4S/2M (or 2S/2M) applications

Product Description

ECUplcs2M,12V,A7,Din

Application Summary

PLC Select 1M Kits are available to upgrade earlier generation ECU platforms. Pre 2009 need to purchase adapter cable AL919347. Replaces AL919323,Multi, (Non-Steer)Connects directly to ECU - no intermediate cables required. PLC Select 1M supports all 2S/1M applications.

Features & Benefits

No intermediate cables required when connecting the wheel speed sensor and trailer power to the ECU
Single fastener design guarantees quick and easier serviceability and reduced maintenance costs
With potted ECU enclosure to withstand impacts, electrical overload, and extreme temperatures
PLC Select 2M ECU that supports all 4S/2M (or 2S/2M) applications

Haldex ABS Electronic Control Unit

Product Attributes

Voltage	12V
Connector Type	DIN
Freight Class	70
Height	4.25 in.
Recommended Use	For use on 4S/2M (or 2S/2M) Valves
Series	PLC Select 2M
Software	SLH-A7
Width	8 in.

Additional Information

Country of Origin (Primary)	CN
Harmonized Tariff Code (Schedule B)	8543709960
Harmonized Tariff Code (HTS)	8543709960
Remanufactured Part	N
Warranty Distance	100000
Warranty Distance UOM	MI
Warranty Special	36 MO, 200,000 MI=ABS - Antilock Braking Systems Including Haldex TRS (Valves, ECUs and Looms Only). 12 MO, 100,000 MI= All Other ABS - Antilock Braking Systems Components. See L20221W.pdf for warranty details
Warranty Time	12
Warranty Time UOM	MO
UPC	00767653333328
VMRS Code	013011076

Part Interchanges

HALDEX AL919342 Cross Reference

We have 3 alternatives for the AL919342 by HALDEX:
