Gates 32040 - HEAD CLAMP
- Part Number
- 32040
- Manufacturer
- GATES CORPORATION
- Description
-
HEAD CLAMP
details
$171
MSRP: $6.74
Save: $5.03
In stock
limited availability at this price!
. Learn more
GATES CORPORATION part description
Technical Specifications
| Weight Lbs | .08 |
| Category Name Description | Top quality clamps with extra-strength construction features. Super Hex clamps feature a 1/2" wide band, while the Minex band is 5/16". |
| Features Advantages | One-piece screw housing is interlocked onto band for extra strength. Solid head forged from one piece of steel, cadmium plated. Hex shaped screw with deep slot - tightens with screwdriver, nutdriver or socket wrench. Tighten to 30 in./lbs. Meets SAE J1508. Durable 200 series stainless steel band and screw housing. |
| Type | Stainless Steel (Standard) |
| Screw Type | Deep Slot Hex-Head |
| Band Width in | .5 |
| Clamping Range Max in | 3 |
| Clamping Range Min in | 1.125 |
| Maximum Torque inlbs | 50 |
| Recommended Torque inlbs | 25-35 |
| Hose ID Max in | 2.5 |
| Hose ID Min in | 2 |
| Size | 40 |
Product Description
Stainless Steel Hose Clamp
Features & Benefits
- Durable 200 series stainless steel band and screw housing
- One-piece screw housing is interlocked onto band for extra strength
- Cadmium-plated solid head forged from one piece of steel
- Hex-shaped screw has a deep slot that tightens with a screwdriver, nut driver or socket wrench
- NOTE: Tighten Minex clamps to minimum 14-16 in. lb. (maximum of 20 in. lb.)
- NOTE: Super Hex clamps to minimum 25-35 in. lb. (maximum of 50 in. lb.)
Product Attributes
| Material | Stainless Steel |
| Adjustment Type | Stainless Steel (Standard) |
| Band Width | .5 IN |
| Maximum Torque | 50 |
| Housing Material | Stainless Steel |
| 3872 | 3 IN |
| 3873 | 1.125 IN |
| 4172 | 2 IN |
| 4438 | 2.5 IN |
| 9816 | 25-35 |
| 9817 | Deep Slot Hex-Head |
| 9867 | 40 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| UPC | 00072053021707 |
| VMRS Code | 053008020 |
| UNSPSC | 31162900 |
Part Interchanges
- Mopar 2448764
- Interstate 2040
- Norton Body Supply 013-40
- Stant SC40
- Velvac 022340
- ACDelco 32040C
- Dayco 91040
- Dayco 92040
- Dayco K40S
- Dayco KH40
- Carquest 1040
- Robertshaw 2040
- Aero-Seal M40S
- Amgauge B40H
- Sterling H140
- Sterling H140MS
- New Holland Agriculture 45014
- Goodyear 51040
- Ideal Tridon 5740190
- Ideal Tridon 670040040
- Ideal Tridon 670040040051
- Hy-Gear 5040
- Hy-Gear 5240
- Hy-Gear 5440
- Hy-Gear 6440
- Murray Gold Seal GS 45
- NAPA 705-1020
- NAPA 705-1080
- NAPA 705-1110
- Sure-Tite 40
- Sure-Tite 40H
- Sure-Tite C40P
GATES CORPORATION 32040 Cross Reference
We have 2 alternatives for the 32040 by GATES CORPORATION:
