CUMMINS part description

Product Description

Heavy-Duty Shock Absorber

Features & Benefits

  • Best-in-class compression and rebound valving systems and proprietary high-performance bushings
  • Pistons are chrome-plated and micro-polished to reduce friction and extend service life
  • Seamless inner tube that’s 40% thicker than the competition for superior strength and seal
  • Extra-thick anti-rust coating with the highest salt/spray rating in the industry
  • Interior and exterior robotic welds provides the strongest breakpoint rating in the industry

Bulldog Heavy Duty Shock Absorber

The Bulldog heavy duty shock absorber offers rugged, professional-grade dampening performance to match the needs of modern truck fleets. Each shock is made with advanced raw materials and designed in partnership with fleet technicians to ensure a consistently smooth drive and reduced downtime.

Product Attributes

Compressed Length (in.) 14.88 IN
Compressed Length (mm) 377.95
Dust Shield Included Yes
Extended Length (in.) 23.86
Extended Length (mm) 606.04
Outer Housing Diameter (mm) 60
Stroke 8.98
Weight (lb.) 10

Additional Information

Core Class NA
Core Group NA
Core Part Number NA
Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 8708800010
Harmonized Tariff Code (HTS) 8708801300
MSDS Sheet Number NA
USA
Regulating State SC
Stock Status S
Warranty Distance 200000
Warranty Distance UOM MI
Warranty Time 24
Warranty Time UOM MO
UPC 00810021212906
VMRS Code 016003016

Part Interchanges

Fits Vehicles

  • Western Star 4700SB (2012-2020)
  • Western Star 4700SF (2012-2020)
  • Freightliner 122SD (2014-2020)
  • International HV507 (2019-2020)
  • Mack Granite (2018)
  • International HV513 (2019-2020)
  • International HV613 (2019-2020)
  • International HV607 (2019-2020)
  • Mack Anthem (2018-2020)
  • International HX520 (2018-2019)
  • Peterbilt 520 (2017-2020)
  • International HX615 (2017-2019)
  • International HX620 (2017-2019)
  • International HX515 (2017-2019)
  • Peterbilt 389 (2008-2018)
  • Kenworth T880 (2014-2020)
  • Kenworth T680 (2013-2020)
  • Mack GU8 (2008-2019)
  • Mack GU7 (2008-2019)
  • Peterbilt 367 (2008-2018)
  • Peterbilt 567 (2014-2018)
  • Mack GU5 (2012-2018)
  • Mack GU4 (2012-2019)
  • Peterbilt 365 (2008-2020)
  • Kenworth T400 (2010-2020)
  • Peterbilt 357 (2002-2008)
  • Peterbilt 320 (2001-2018)
  • Peterbilt 348 (2010-2020)
  • Freightliner 114SD (2012-2020)
  • Freightliner 108SD (2012-2020)
  • Kenworth T270 (2008-2020)
  • Kenworth T370 (2008-2018)

Cummins® is a worldwide leader in the production of engines, agricultural components, and other power-generating devices for various industries, including medium and heavy duty trucks, light commercial vehicles, buses, agriculture, and construction. Founded in 1919, this company stays true to its mission of making people's lives better by continuously improving its product line-up and introducing new solutions for a more prosperous world. Its core values—integrity, diversity and inclusion, excellence, caring, and teamwork—are what make it a successful company today—a worldwide leader with a network of more than 600 company-owned and independent distributors and almost 6,000 dealers in approximately 190 countries.
