Name: Gates 24836 2.25” × 3’ Silicone Radiator Hose
SKU: 24836
Price: 100.08 USD
Availability: InStock

GATES CORPORATION part description

Application
Features Advantages	CAUTION: Do not use for fuel or oil transfer applications. Extra long-lasting hose constructed with silicone rubber. Ideal for extremely high temperatures in radiator and heater applications. Excellent for extreme ambient and radiant temperature conditions. Resists weathering, ozone, heat and coolant deterioration. Silicone tube and cover resist prolonged exposure to under-hood and coolant heat. Exceeds SAE 20R1 (Class A Standard Wall). Also can be used for emission hose applications.
Packaging
Specifications
Centerline Length (ft)	3
Inside Diameter (in)	2.25
Weight
Weight (Lbs.)	.98
Working Pressure
Working Pressure (psi)	75

Features & Benefits

For extremely high temperature radiator, heater, and coolant transfer applications. Engineered with extra long-lasting silicone rubber for extreme ambient and radiant temperature conditions. The silicone tube and cover resist prolonged exposure to under-hood and coolant heat, weathering, ozone, and deterioration. Use Gates thermoplastic clamps or silicone hose clamps to complete assembly.
Temperature: −70ºF to +350ºF (−56°C to +177°C)
Use thermoplastic clamps or silicone hose clamps
Exceeds SAE 20R1 (Class A Standard Wall)

Product Description

Straight Silicone Coolant Hose

Application Summary

2022-14 Kenworth, T370, Paccar PX-9 Diesel, Lower - Eng. To Pipe

Features & Benefits

Distinct blue cover
Resists weathering, ozone, heat and coolant deterioration
Exceeds SAE 20R1 (Class A Standard Wall)
Temperature Range: -70 Deg. F to +350 Deg. F (-56 Deg. C to +177 Deg. C)
Note: For a maintenance free connection, use PowerGrip SB clamps
Caution: Do not use for fuel or oil transfer applications

Product Attributes

Material	Silicone
Construction	4-Ply
End 1 Inside Diameter	2.25 in
End 2 Inside Diameter	2.25 in
2035	3 FT
2053	75 PS
9839	No

Additional Information

Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	4009310000
UPC	00072053113105
VMRS Code	042004050
UNSPSC	40142000

Part Interchanges

GATES CORPORATION 24836 Cross Reference

We have 1 alternatives for the 24836 by GATES CORPORATION:

41711912

Fits Vehicles

International 7400 (2014)
Mack CV (2007)
Kenworth K370 (2020)
Peterbilt 520 (2018, 2020)
Kenworth T170 (2020)
Mack CHN (2005)
Peterbilt 567 (2019-2021)
International 7500 (2014, 2016)
Peterbilt 385 (2006)
Peterbilt 384 (2012)
Mack LEU (2011)
Kenworth T800 (2013-2014)
Peterbilt 325 (2013-2014)
Peterbilt 382 (2011-2016)
Peterbilt 365 (2013-2014, 2016-2017, 2019)
Peterbilt 320 (2012-2013, 2016-2017)
Peterbilt 340 (2010)
Peterbilt 348 (2010-2021)
Peterbilt 330 (2012, 2015, 2021)
Peterbilt 335 (2008-2010)
Peterbilt 337 (2010-2021)
Kenworth T370 (2008-2009, 2011-2020)
Kenworth T270 (2010-2012, 2014-2017, 2019-2020)
