Buyers Products ch101120 - Remote Mount Hydraulic Pump With Manual Valve And 2 Inch Diameter Gear
- Part Number
- ch101120
- Manufacturer
- BUYERS PRODUCTS
- Description
-
Remote Mount Hydraulic Pump With Manual Valve And 2 Inch Diameter Gear
details
$44749
MSRP: $631.29
Save: $183.80
In stock
limited availability at this price!
. Learn more
BUYERS PRODUCTS part description
Specifications:
| Displacement: | 3 in.³/r |
| Displacement : | 16 GPM |
| Gear Width: | 2.000" |
| Input Mount Type: | Frame Mount |
| Material: | Cast Iron |
| Maximum Rotations Per Minute (RPM): | 2000 RPM |
| Mount Type: | Frame Mount |
| Shaft Size: | 1 |
| Shaft Type: | Round/Keyed |
| Ports (rear/side): | Rear |
| Inlet Port Size: | 1 1/4 NPT |
| Maximum Pressure: | 2500 PSI |
| Direct or Remote Mount: | Remote Mount |
| Outlet Port Size: | 3/4 NPT |
| Rotation: | Clockwise or Counterclockwise |
| Gear Size: | 2.00" |
| Flow at 600 RPM: | 9.66 GPM |
| Flow at 1000 RPM: | 16.1 GPM |
| Flow at 1800 RPM: | 29 GPM |
| Flow at 900 RPM: | 14.49 GPM |
| Flow at 1200 RPM: | 19.2 GPM |
| Flow at 1500 RPM: | 24.15 GPM |
| Flow at 2100 RPM: | 33.81 GPM |
| Rear Port Size: | 3/4 NPT |
| Suction Port Size: | 1 1/4 NPT |
| Product Code: | 620 |
Buyers Products Hydraulic Dump Pump
The Buyers Products hydraulic dump pump is designed as a compact and efficient source of hydraulic power for your vehicle. It is primarily used for dump operations with 2 or 3-line plumbing.
Features & Benefits
- A highly reliable remote mount pump with a manual relief valve and 2-inch diameter gear
- With air-controlled operation (controller is sold separately)
- Includes a 4 bolt SAE mounting flange, 7/8 in. by 13 spline shaft, and third line sleeve
- Commonly used in small dump applications and truck and trailer hydraulic systems
Product Description
Remote Mount Hydraulic Pump with Manual Valve and 2in. Diameter Gear
Features & Benefits
- A highly reliable remote mount pump with a manual relief valve and 2-inch diameter gear
- With air-controlled operation (controller is sold separately)
- Includes a 4 bolt SAE mounting flange, 7/8 in. by 13 spline shaft, and third line sleeve
- Commonly used in small dump applications and truck and trailer hydraulic systems
Buyers Products Hydraulic Dump Pump
The Buyers Products hydraulic dump pump is designed as a compact and efficient source of hydraulic power for your vehicle. It is primarily used for dump operations with 2 or 3-line plumbing.
Product Attributes
| Direct Or Remote Mount | Remote Mount |
| Flow At 1000 Rpm | 16.1 GPM G2 |
| Flow At 1200 Rpm | 19.2 GPM G2 |
| Flow At 1500 Rpm | 24.15 GPM G2 |
| Flow At 1800 Rpm | 29.0 GPM G2 |
| Flow At 2100 Rpm | 33.81 GPM G2 |
| Flow At 600 Rpm | 9.66 GPM G2 |
| Flow At 900 Rpm | 14.49 GPM G2 |
| Flow Rate | 3 in.³/r |
| Flow Rate | 16 GPM G2 |
| Gear Size | 2.00 IN |
| Gear Width | 2.000 IN |
| Inlet Port Diameter | 1 1/4 NPT |
| Input Mount Type | Frame Mount |
| Material | Cast Iron |
| Maximum Pressure | 2500 PSI PS |
| Maximum Rpm | 2000 RPM R3 |
| Mounting Type | Frame Mount |
| Outlet Port Diameter | 3/4 NPT |
| Port Size | 1 1/4 NPT IN |
| Port Type | Rear |
| Rear Port Size | 3/4 NPT IN |
| Rotation | Clockwise or Counterclockwise |
| Shaft Diameter | 1.000 IN |
| SHAFT TYPE | Round/Keyed |
Buyers Products® is a global leader in manufacturing and distributing truck and trailer hardware, toolboxes, hydraulics, cables and controls, electrical and lighting components, pneumatics, and truck equipment and accessories. All these products are engineered, produced, and assembled in the USA, where the company was first founded in 1946. From a modest distributor of truck and trailer parts, Buyers Products has grown into one of the largest truck parts manufacturers and distributors in the heavy duty truck and equipment market today. Its years of expertise in the industry have allowed it to refine its manufacturing capabilities. From forging, stamping, and laser cutting to robotic welding and powder coating, Buyers Products integrates its dedication to quality in manufacturing products that provide value to its customers.
