National Seals 711103 - Auto Trans Seal
- Part Number
- 711103
- Manufacturer
- FEDERAL MOGUL-NATIONAL SEALS
- Description
-
Auto Trans Seal
details
$2349
MSRP: $32.36
Save: $8.87
In stock
limited availability at this price!
. Learn more
FEDERAL MOGUL-NATIONAL SEALS part description
Product Description
Auto Trans Ext. Housing Seal
Application Summary
2015-2017 Chrysler 200 (Transmission Code: 948TE & Transmission Base Gear: 9 & Transmission Control Type: Automatic & Drive: AWD / Qualifier: with Chrysler 948TE Transmission); 2015-2019 Jeep Renegade (Transmission Code: 948TE & Transmission Base Gear: 9 & Transmission Control Type: Automatic & Drive: AWD / Qualifier: with Chrysler 948TE Transmission); 2017-2019 Jeep Compass (Transmission Code: 948TE & Transmission Base Gear: 9 & Transmission Control Type: Automatic & Drive: AWD); 2014-2019 Jeep Cherokee (Transmission Code: 948TE & Transmission Base Gear: 9 & Transmission Control Type: Automatic & Drive: AWD, 4WD / Qualifier: with Chrysler 948TE Transmission); 2016-2019 Fiat 500X (Transmission Code: 948TE & Transmission Base Gear: 9 & Transmission Control Type: Automatic & Drive: AWD)
Features & Benefits
- Design type: spring loaded; multi-lip
- Temperature range: -20degF to 300degF / -29degC to 49degC
- Resistance to EP lubricants
- Low swell in hydrocarbon fluids
- Delivers quality and reliable performance for every type of repair
Product Attributes
| Material | Polyacrylate |
| Helix Type | Bi-Directional Lip Design |
| Housing Bore (inch) | 1.969 IN |
| Housing Bore (mm) | 50.000 MM |
| Outside Diameter (inch) | 1.976 IN |
| Outside Diameter (mm) | 50.200 MM |
| Part Description | Oil Seal |
| Series | 711100 |
| Shaft (inch) | 1.457 IN |
| Shaft (mm) | 37.000 MM |
| Type | 32 |
| Unit of Dimension | Metric |
| Width (inch) | 0.315 IN |
| Width (mm) | 8.000 MM |
Additional Information
| Country of Origin (Primary) | TW |
| Harmonized Tariff Code (Schedule B) | 4016931020 |
| Harmonized Tariff Code (HTS) | 4016931020 |
| UPC | 00019826208866 |
Part Interchanges
Fits Vehicles
- Jeep Compass (2017-2019)
- Fiat 500X (2016-2019)
- Jeep Renegade (2015-2019)
- Chrysler 200 (2015-2017)
- Jeep Cherokee (2014-2019)
The National Seals® is a proud designer and supplier of wheel bearings and oil seals with a focus on quality, safety, and continuous improvement. The key to its success may be attributed to its hardworking and dedicated team of engineers who keep pace with the industry to provide premium wheel end solutions for light and commercial vehicle applications. Federal-Mogul acquired the National Seal Division of the National Motor Bearing Company only in 1942. But the brand National Seals has already cemented itself as one of the most respected names in the industry. Over the years, it has remained fully committed to providing only the highest quality seals and bearings that meet or exceed OE specifications.
