Name: TrakMotive TO8018 NEW CV AXLE
SKU: to8018
Price: 63.49 USD
Availability: InStock

TRAKMOTIVE part description

Product Description

CV Axle Shaft

Application Summary

Chevrolet;Geo;Toyota

Product Attributes

ABS Ring Tooth Count	48
ABS Ring Type	Toothed
Abs Tone Ring Included	Yes
Axle Bolt Hex Size (mm)	N/A
Axle Bolt Length (mm)	N/A
Axle Bolt Thread Size	N/A
Axle Nut Head Type	Hex
Axle Nut Height (in)	5/6
Axle Nut Height (mm)	21
Axle Nut Hex Size (in)	1 1/6
Axle Nut Hex Size (mm)	30
Axle Nut Included	Yes
Axle Nut Length (in)	1 1/3
Axle Nut Length (mm)	34.6
Axle Nut Locking Type	Cotter Pin
Axle Nut Thread Size	M22*1.5
Boot Material	Neoprene
Inboard Bolt Head Size (in)	N/A
Inboard Bolt Head Size (mm)	N/A
Inboard Bolt Length (in)	N/A
Inboard Bolt Length (mm)	N/A
Inboard Bolt Thread Size	N/A
Inboard Joint Type	Male
Inboard Shaft Connection Style	Male
New Or Remanufactured	New
Number of Bolt Holes	N/A
Number Of Inboard Joint Bolt Holes	N/A
Number Of Inboard Shaft Bolts	N/A
Number Of Inboard Splines	23
Number Of Outboard Joint Bolt Holes	N/A
Number Of Outboard Shaft Bolts	N/A
Number Of Outboard Splines	26
Outboard Bolt Head Size (in)	N/A
Outboard Bolt Head Size (mm)	N/A
Outboard Bolt Head Type	N/A
Outboard Bolt Length (in)	N/A
Outboard Bolt Length (mm)	N/A
Outboard Joint Bolt Thread Size	N/A
Outboard Joint Type	Conventional
Outboard Shaft Connection Style	Conventional
Overall Compressed Length (in)	24.06
Overall Compressed Length (mm)	611

Additional Information

Country of Origin (Primary)	CN
Harmonized Tariff Code (HTS)	8708508500
UPC	00844084080189

Part Interchanges

TRAKMOTIVE TO8018 Cross Reference

We have 1 alternatives for the TO8018 by TRAKMOTIVE:

APW INTERNATIONAL TO8003A
