Name: TrakMotive MZ8134 NEW CV AXLE
SKU: mz8134
Price: 77.99 USD
Availability: InStock

TRAKMOTIVE part description

Product Description

CV Axle Shaft

Application Summary

Mazda

Product Attributes

ABS Ring Tooth Count	44
ABS Ring Type	Toothed
Abs Tone Ring Included	Yes
Axle Bolt Hex Size (mm)	N/A
Axle Bolt Length (mm)	N/A
Axle Bolt Thread Size	N/A
Axle Nut Head Type	Hex
Axle Nut Height (in)	1
Axle Nut Height (mm)	24
Axle Nut Hex Size (in)	1 1/4
Axle Nut Hex Size (mm)	32
Axle Nut Included	Yes
Axle Nut Length (in)	1 1/2
Axle Nut Length (mm)	37
Axle Nut Locking Type	Stake
Axle Nut Thread Size	M22*1.5
Boot Material	Neoprene
Inboard Bolt Head Size (in)	N/A
Inboard Bolt Head Size (mm)	N/A
Inboard Bolt Length (in)	N/A
Inboard Bolt Length (mm)	N/A
Inboard Bolt Thread Size	N/A
Inboard Joint Type	Female
Inboard Shaft Connection Style	Female
New Or Remanufactured	New
Number of Bolt Holes	N/A
Number Of Inboard Joint Bolt Holes	N/A
Number Of Inboard Shaft Bolts	N/A
Number Of Inboard Splines	28-2T
Number Of Outboard Joint Bolt Holes	N/A
Number Of Outboard Shaft Bolts	N/A
Number Of Outboard Splines	28
Outboard Bolt Head Size (in)	N/A
Outboard Bolt Head Size (mm)	N/A
Outboard Bolt Head Type	N/A
Outboard Bolt Length (in)	N/A
Outboard Bolt Length (mm)	N/A
Outboard Joint Bolt Thread Size	N/A
Outboard Joint Type	Conventional
Outboard Shaft Connection Style	Conventional
Overall Compressed Length (in)	23.62
Overall Compressed Length (mm)	600

Additional Information

Country of Origin (Primary)	CN
Harmonized Tariff Code (HTS)	8708508500
UPC	00844084061348

Part Interchanges

TRAKMOTIVE MZ8134 Cross Reference

We have 1 alternatives for the MZ8134 by TRAKMOTIVE:

APW INTERNATIONAL MZ8339A

Based in Redlands, CA, TrakMotive® is a North American distributor of aftermarket CV axles and shaft assemblies for light duty trucks and ATVs. It offers a wide selection of premium-quality axles as well as specialty axles for lifted vehicles and fleet/rideshare applications. The company also supplies motorized window regulators for the aftermarket. TrakMotive products are engineered to the highest standards, ensuring they meet or even exceed original equipment manufacturer specifications in fit, form, and function. All products are manufactured in-house at ISO 9001:2015 and IATF 16949.2016-certified facilities and under supervision by the world’s top engineers and technicians, ensuring quality that satisfies the needs of the company’s most demanding customers.
