Name: Rancho RS55124 Rancho Shock
SKU: rs55124
Price: 76.99 USD
Availability: InStock

RANCHO part description

Product Description

RS5000X Shock Absorber

Application Summary

1998-2000 Isuzu Hombre (Rear); 1987-1996 Dodge Dakota (Rear) (Drive: 4WD); 1999-2000 Cadillac Escalade (Rear) (Drive: 4WD); 1992-2005 Chevrolet Blazer Base Xtreme LS (Rear) (Drive: 4WD); 1992-1999 Chevrolet K1500 Suburban (Rear); 1992-1999 Chevrolet K2500 Suburban (Rear); 1983-1994 Chevrolet S10 Blazer (Rear); 1982-2004 Chevrolet S10 Base Tahoe Durango Sport Baja EL LS SS Xtreme ZR5 (Rear) (Drive: RWD, 4WD); 1995-2000 Chevrolet Tahoe (Rear) (Doors: 4, 2 & Liter: 5.7 & Drive: 4WD, RWD); 1992-1999 GMC K1500 Suburban (Rear); 1992-1999 GMC K2500 Suburban (Rear); 1992-2005 GMC Jimmy (Rear); 1983-1991 GMC S15 Jimmy (Rear); 1983-1990 GMC S15 (Rear) (Drive: 4WD, RWD); 1991-2004 GMC Sonoma (Rear) (Drive: 4WD); 1992-2000 GMC Yukon (Rear) (Doors: 2, 4 & Liter: 5.7 & Drive: RWD, 4WD); 1991-2001 Oldsmobile Bravada (Rear)

Features & Benefits

IMPROVED HANDLING AND PERFORMANCE -- Cross Tuned technology featuring exclusive rebound valving system and advanced compression phase improves overall handling and performance on and off road
MINIMIZES ROUGH RIDE -- Exclusive Progressive Engagement Valving is custom-tuned for each vehicle to help reduce initial impacts at low speeds and minimizes a rough ride
STRONG AND DURABLE -- Features a 16mm nitro-carburized piston rod to resist scuffs & corrosion, double-welded loops at stress areas, 35mm sintered iron piston for enhanced structural integrity and polyvinyl protective boot
HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248degF
SMOOTH PERFORMANCE -- Polyurethane rebound bumper and rubber bushings help absorb ride harshness while the fluon-banded piston enhances responsiveness to changing road conditions for an overall smoother ride
REDUCES FADE -- Nitrogen gas pressurized to 150 PSI to minimize air-to-oil mixture to reduce damping performance fade and foaming
MAINTAINS VEHICLE CONTROL -- Compression Control Valve is custom-tuned for each vehicle to regulate fluid transfer to absorb impacts without disc flutter and help maintain shock motion control
BUILT TO LAST -- Low-friction, self-lubricating seal retains gas and oil for quicker rebound and smoother compression while the application-specific piston delivers heightened control of shock motion due to the expanded piston area
BUY WITH CONFIDENCE -- Comes with Rancho's Limited Lifetime Warranty

Product Attributes

Compressed Length	14.07 IN
Travel Length	10.14 in
Finish	Painted
Grade Type	Performance
Extended Length	24.21 in
Gas Charged	Yes
Adjustable Damping	No
Dust Shield Included	Yes
9789	XP4
9791	LS40
9801	35 MM
Internal Construction Type	Dual Tube
Lower Mount Type	Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 1.11/16" Sleeve OAL
Part Description	Shock Absorber
Upper Mount Type	Cross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.7/16" Pin Length (Hole Center to Center)

Additional Information

Country of Origin (Primary)	US
Canadian Harmonizing Tariff Code	8708803000
Harmonized Tariff Code (Schedule B)	8708801600
Harmonized Tariff Code (HTS)	8708801600
MSDS Sheet Number	01164
UPC	00039703007757

Part Interchanges

Fits Vehicles

Oldsmobile Bravada (1991-1994, 1996-2001)
GMC Yukon (1992-2000)
GMC Sonoma (1991-2004)
GMC S15 (1983-1990)
GMC Jimmy (1992-2005)
GMC S15 Jimmy (1983-1991)
GMC K2500 Suburban (1992-1999)
GMC K1500 Suburban (1992-1999)
Chevrolet Tahoe (1995-2000)
Chevrolet S10 (1982-2004)
Chevrolet S10 Blazer (1983-1994)
Chevrolet K2500 Suburban (1992-1999)
Chevrolet K1500 Suburban (1992-1999)
Chevrolet Blazer (1992-2005)
Cadillac Escalade (1999-2000)
Dodge Dakota (1987-1996)
Isuzu Hombre (1998-2000)

All shocks are built to take the pressure, but not all are as tough as a Rancho®. For more than half a century, Rancho has been the leading authority on heavy duty suspension solutions for off-road applications. Rancho shocks have built-in features not found in other competing shocks, including extra-thick pistons and piston rods, multi-stage valving technology, and protective boot, for flexible performance in any terrain without compromising durability. They also offer premium lifting and leveling assemblies that are easy to install and improve ride quality significantly without extensive modifications to the vehicle. All Rancho shocks are tested and certified to comply with international quality and safety standards.
