Name: National Seals 710971 Trans Case Seal
SKU: 710971
Price: 15.99 USD
Availability: InStock

FEDERAL MOGUL-NATIONAL SEALS part description

Oil Seal

Product Description

Transfer Case Output Shaft Seal

Application Summary

2001-2012 Ford Escape (Drive: 4WD / Qualifier: with Power Transfer Unit (PTU) Transfer Case); 2017 Ford Explorer (Drive: 4WD / Qualifier: with Power Transfer Unit (PTU) Transfer Case); 2005-2011 Mercury Mariner (Drive: 4WD / Qualifier: with Power Transfer Unit (PTU) Transfer Case); 2001-2009 Mazda Tribute (Drive: 4WD, AWD / Qualifier: with Power Transfer Unit (PTU) Transfer Case)

Features & Benefits

Design type: spring loaded; multi-lip
Temperature range: -40degF to 400degF / -40degC to 204degC
Excellent high temperature capabilities
Compatible with wide range of fluids
Delivers quality and reliable performance for every type of repair

Product Attributes

Inside Diameter	1.811 IN
Thickness	0.455 IN
Outside Diameter	2.780 IN
Sealing Material	Fluoro-Elastomer
Flanged Outside Diameter (inch)	3.118 IN
Flanged Outside Diameter (mm)	79.200 MM
Helix Type	Bi-Directional Lip Design
Housing Bore (inch)	2.778 IN
Housing Bore (mm)	70.550 MM
Material	Fluoro-Elastomer
Outside Diameter (inch)	2.780 IN
Outside Diameter (mm)	70.600 MM
Overall Width With Side Lip (mm)	15.000 MM
Overall Width With Side Lip (inch)	0.591 IN
Part Description	Oil Seal
Series	710900
Shaft (inch)	1.811 IN
Shaft (mm)	46.000 MM
Type	87
Unit of Dimension	Inch
Width (inch)	0.455 IN
Width (mm)	11.560 MM

Additional Information

Country of Origin (Primary)	TW
Harmonized Tariff Code (Schedule B)	4016931020
Harmonized Tariff Code (HTS)	4016931020
UPC	00019826209580

Part Interchanges

Fits Vehicles

Ford Explorer (2017)
Mercury Mariner (2005-2011)
Ford Escape (2001-2012)
Mazda Tribute (2001-2006, 2008-2009)

The National Seals® is a proud designer and supplier of wheel bearings and oil seals with a focus on quality, safety, and continuous improvement. The key to its success may be attributed to its hardworking and dedicated team of engineers who keep pace with the industry to provide premium wheel end solutions for light and commercial vehicle applications. Federal-Mogul acquired the National Seal Division of the National Motor Bearing Company only in 1942. But the brand National Seals has already cemented itself as one of the most respected names in the industry. Over the years, it has remained fully committed to providing only the highest quality seals and bearings that meet or exceed OE specifications.
